TFD800C Ultrasonic Flaw Detector
Product Description:
USB memory knob digital ultrasonic flaw detector TFD800C mini total 1kg with battery
Simple operation with fast rotary knob adjustments
use in direct sunlight and operation at extreme temperatures…
Product Info
Automated calibration Automated gain
•Automated make video of test process and play
•AWS D1.1,DAC (6dBDAC), AVG, TCG & B scan,28 DGS curves
Pulse can be adjusted by customer
High-speed capture and very low noise
•Solid metal housing (IP65), rubber plastic dust cover included
•High contrast viewing of the waveform from bright
•Powerful pc software and reports can be export to excel
Small size, light weigh model, total 1kg with battery
Knob design, fast operation
USB memory stick for no limit data transmission
Features :
• Automated calibration of transducer, angle, Zero point and Velocity
• Automated gain,Peak Hold and Peak Memory
• Automated display precise flaw location(Depth d,level p,distance s,amplitude,sz dB,ф)；
• Automated switch three staff gauge ((Depth d,level p,distance s)
• 100 independence setup, any criterion can be input freely, we can work in the scene without test block
• Big memory of 1000 A graph
• RS232/USB 2.0 port,communication with pc is easy
• The embeded software can be online updated
• Li battery, continue working time up to 10 hours
Other assistant function
• Display freeze
• Automated echo degree
• Angles and K-value
• Lock and unlock function of system parameters
• Dormancy and screen savers
• Electronic clock calendar
• Two gates setting and alarm indication
• High-speed capture and very low noise
• Automated make video of test process and play, USB memory disk,no limit for video time.
Main Technical Index:
Title | Parameter | Title | Parameter |
Measuring Range(mm) | 0 ～ 10000 | Measurement Mode | Single,Dual,Thru |
Vertical Linearity Error | ≤3% | Reject | 0~80% |
Horizontal Linearity Error | ≤0.1% | Pulse Displacement(μs) | -20 ～ +3400 |
Sensitivity Leavings | ≥62dB | Zero(μs) | 0.0 ～ 99.99 |
Pulse Displacement | ≥34dB | Port Type | BNC |
Resolving Power | ≥36 | Operating Temperature (℃) | -20～50 |
Frequency Range(MHz) | 0.5 ～ 20 | H×W×D(mm) | 210×156×40 |
Gain(dB) | 0 ～ 120 | Weight(kg) | 1.0 (with battery) |
Material Velocity(m/s) | 1000 ～ 15000 |
TFD800C Standard Configuration
No. | Item | Quantity |
1 | Main Body | 1 |
2 | Straight Beam Probe | 1 |
3 | Angle Probe | 1 |
4 | Machine-probe Cable | 2 |
5 | Battery Module | 1 |
6 | Power Adapter (Charger) | 1 |
7 | Manual | 1 |
8 | Instrument Case | 1 |
9 | Datapro Software | 1 |
10 | USB communication Cable | 1 |
Please notice: we will ship USB flash disk with each ultrasonic flaw
detector, in the USB flash disk have the video to show
how to calibrate the probe and how to operate the instruments.
