Product Package
1 x DDCSV3.1 CNC Offline Controller （3/4 Axis Optional）
1 x 4 Axis MPG handwheel
1 x 4GB USB Flash Disk
1 x USB Extension Cable Accessories
1 x Mounting bracket
1 x Handwheel Hook
3 x Closed loop driver
3 x Closed loop motor
3 x Motor extension cord
3 x Encoder extension cable
Product Description
DDCSV3.1 is 3 or 4 axis motion controller for stepper and servo systems. We are very proud of this product; it combines great power with a tiny footprint and is easy to use. After a very short time you will be familiar with the functions and this manual will help you. The highest output pulse per axis is 500 KHz. The pulse width is adjustable (refer to driver manual). The control period of each position is only 4 milliseconds. This provides high control precision for stepper motors and servo motors.
Features:
1) American and imperial units in the system can be converted;
2) Handwheel MPG master control page, file page and configuration page, extended keyboard can also operate and edit controller;
3) New trial cut function, single line processing,
4) The tool setting function is increased to 4 modes;
5) The software is greatly adjusted and optimized, and the parameter configuration is greatly increased to make the performance more powerful and reliable;
6) Controller language is Chinese/English/Russian
Appearance and size：
Closed-Loop Stepper Motor Product Description
Drive Model: JSSD2505M (Nema 23, for 57 stepper motor)
Pulse Signal: 3.3V/5V/24V compatible. No string resistor required
Voltage Range: DC16-70V (New Version: DC24-80, send in random)
Subdivision Setting: 800-51200 subdivision
The new 32-bit DSP digital 57 closed-loop stepper motor driver, engraving machine, CNC equipment available. PWM current control, low noise, high speed torque is 40% larger than ordinary drives.
Motor model: SSD257EC80E1
Motor current: 4A
Output torque: 2.2N.m
Body length: about 99MM
Outlet mode: single output shaft
Rated speed: 1000 rpm (no-load speed: 2000 rpm)
Outlet mode: two-phase four-wire (must be wired according to motor label)
feature
1): Full-closed control, the motor is equipped with 1000 line encoder, close to 100% torque output, subdivision setting range is 2-256, high speed response, high speed
2): Optical isolation fault alarm output interface ALM, current loop bandwidth (-3dB) 2KHz (typical), speed loop broadband 500Hz (typical)
3): Position loop broadband 200Hz (typical), can be downloaded or changed parameters with RS232 serial communication
4): overcurrent, I2T, overvoltage, undervoltage, overheating, overspeed, out of tolerance protection
size
Electronic Handwheel MPG Product Description
The CNC 4 Axis handheld controller MPG Pendant with x1, x10, x100 selectable, the MPG pendant for 4 axis CNC machine, it equipped with our popular machined MPG unit with 4axis and scale selector, LED indicator also send feedback from the CNC machine to user about the status of the unit.
Features :
- x1, x10, x100 switch
- X,Y,Z,4th axis selector switch (5th, 6th)
- LED indicator
- High quality professional chassis
- 6ft extendable high quality shielded cable cord
- Magnetic base holder can place anywhere on the machine steel surface
- Required 5V+, 150mA, power for MPG
- Phase output is A ,/A and B,/B;
- TTL output, drive capability +-20mA;
Colour: Black
Material: metal + plastic
Resolution: 100PPR
Power:5v
Current:≤80mA
Output Voltage:Output H is high level: VCC-2.5V
Output is low and high level: ≤0.4v
Axis:X,Y,Z,A
Ratio:x1,x10,x100
Max response frequency:10Khz
size：
