Premium Block Plane, Simon Tools
Plane length: 167mm
Plane width: 54mm
Blade width: 35mm
Blade angle: 25 degrees
Frog seat angle: 15 degrees
Adjustment method: Norris screw adjustment
Plane blade material: Austria Böhler special steel K340
Heat treatment hardness: HRC60-62
Plane sole material: 3CR13
Other accessories material: aluminum alloy, stainless steel
Processing technology: CNC machiningThe sole of the plane is ground by a precision grinder to ensure a flat bottom surface.
The Norris adjuster is CNC turned and milled by a non-slip texture machine. Each groove corresponds to a 40-degree rotation angle, and the planer advances 0.03mm for each rotation to achieve precise adjustment of the planing amount.
