SIZE:
Reliability & Safety
CNC Software Alarm
Alarms of program error, operation error, over-travel error, PLC error and IO communication error
Software Language:
Chinese,English
High-speed High-precision Optimization:
Interpolation Algorithms
T-type, S-type and LEP algorithms
Operations:
WCS Setting
Supporting WCS G54-G59 and Work Zero saving
Processing Technology
Array function,Mirror&rotate,Cycle
Convenitent Operation
Handwheel guide,Breakpoint resurne,Tool selection
Toolpath Program:
Supported File Format
*.g;*.nc;*.ug;*.demo;*.iso;*.eng;*.cut;*.dxf;*.plt;*.txt
Compensation:
Compensation Type: Screw error
compensation, Backlash
compensation, AQE
compensation, Tool
compensation
Tool Management:
Tool Measurement Mode Auto measurement,
Manual
measurement
Tool Calibration Type Fixed calibration,
Mobile calibration,
First calibration &
Calibration after tool
change
Spindle:
Analog Voltage Output 0-10V
Communication Mode:
PCI
Control Signals:
Plus Frequency 160KHZ
Control Mode Position control
Control Signal Type Differential signals
Position Signal Type Pulse+Direction
CNC specification standard:
Number of Axes Supported three axes
Rotary Axes X/Y as a rotary axis(optional)
