spindle motor 2.2kw 24000rpm 2200w 220V/380V cnc engraving machine 80mm water cooling spindle motor
Packling list
1pcs 2.2kw spindle 80*213mm
1pcs ER20 collet
Specifications
2.2KW Spindle Motor Specifications:
Brand: Changsheng
Spindle speed: 0 - 24000r/min
Rated power: 2.2kw
Voltage: 220V
Frequency: 400HZ
Dimensions:
D: 80 mm
L: 213mm
Shaft connection: ER20 chuck
Lubrication: Grease
Bearing: Front C7005 DT P4 Level 2, back-C7002 P4 Level 2
Weight: 5kg
Power interface: choose GX16 waterproof air interface, there were 1234, 123 respectively by the inverter power supply (U, V, W), 4 inverter earthed.
