| 1 Pcs DM100D Controller |
| 1 Pcs NCH02 Patch Panel |
| 1 Pcs U Disk |
| Read G-Code From U-Disk (Operation Without Computer |
| 8 Ports Photoelectric Isolated Input Interface |
| 5 Ports Photoelectric Isolated Output Interface |
| 1 Port 0-10V Spindle Speed Analog Output Interface ( Can Change To PWM Output) |
| Can Support 5 Axis Stepper Systems, 125Khz Pulse Output For Every Axis |
| ARM Motion Control Chip |
| Main Device Is 24VDC Power Supply Input, Current Should Be Higher Than 1A |
| Support Standard MPG and NVMPG |
| 3.5" TFT Screen |
| 19 User Key |
Keys Icon | Definition | Keys Icon | Definition |
| Page Left |
| 1: Z axis Down;2: Home;3: Data 6 Input |
| Page Right |
| Spindle manual Start/Close |
| 1: Cancel;2: Exit |
| 1: X axis moves left； 2: Probe； 3: Data 1 Input. |
| Shift,This key will activate 2nd Mode |
| 1: Y axis moves forward； 2: Y Axis Select3: Data 2 Input |
| 1: A axis rotates in forward direction;2: A axis select;3: Data 7 Input |
| 1: X axis moves right；2: X Axis Select3: Data 3 Input |
| 1: B axis rotates in forward direction;2: B axis select;3: Data 8 Input |
| Start operation |
| 1: Z axis Up;2: Z axis select;3: Data 9 Input |
| Pause operation |
| RESET |
| 1: Y axis move backward；2: Data 0 Input |
| 1: A axis rotates in reserve direction;2: 0-clearing;3: Data 4 Input |
| 1: Mode of Step/Continuous/MPG Selection2: Data . Input |
| 1: B axis rotates in reserve direction;2: Go To Zero funciton;3: Data 5 Input |
| 1: Increase the number clockwise；2: Decrease the number Counter-clockwise3: Push the button to Confirm |
| USB Interface |
| Main Power Interface |
| Input and Output Power |
| Input Interface Such As Limit Origin |
| MPG Interface |
| Universal Output Interface |
| Spindle Control Output Interface |
| Drive Control Interface |
