SPECIFICATION
Frame size (L - W -H): 590x980x160mm
Working area( X - Y): 810 x 460mm, Extends to 810x1030mm
Dot Pitch: 0.075mm, 338dpi
Pixel: 6133 x 10800 px
Drive accuracy: 0.01mm
Max Move Speed: X:1000mm/s(with A40640 module 204g), Y:750mm/s
Frame Material: High precision All-aluminum alloy and PC material hybrid frame
Structure Technology: Y-axis fit adjustable design, X-axis stress fit assembly
Structure Feature: Fit, High precision, stablize, smooth, no oil, easy maintenance, long life
Vertical Carving: Yes (45°)
Motor Size: 42 x 42 x 34mm
Motor Drive Current: 0.9A
Module Height Adjuster：Yes
Home: Rear Left
Origin: Front Left
Compatible Modules: All NEJE 4pin Laser Moudle, included E40 24V Laser module (The motherboard is above v1.1.0)
