Portable and stable design
-Only 4 screws to complete the assembly.
-380x300mm device size,170x170mm working area.
Join the NEJE community and learn more about creating-The above pictures are all created by real NEJE fans, and more creative possibilities are waiting for you to discover.
The most advanced diode laser control system so far-NEJE control system has built-in OTA software and firmware upgrade function, NEJE software and APP provide a very portable operating experience, whether you are a laser CNC novice or a professional laser expert, it can provide you with a comprehensive operating experience.
Safety is always the most important
-The MEMS gyroscope will record the state of the machine. When the device moves, the machine will automatically stop working to avoid the risk of pets or misuse.
General Specification
Model： NEJE 3 N30610
Optical Power: 450nm 2.5W
Control Board: 2 x MCU + Wireless control + MEMS
Satety Protection: MEMS
Working Size: 170 x 170 mm
Pixel: 2266 x 2266 px
Dot pitch: 0.075mm
Software: NEJE APP for Android, NEJE Wireless APP for iOS / macOS, NEJE software for windows, LaserGRBL with firmware GRBL1.1f.,LightBurn Software with firmware GRBL1.1f.
LightBurn ( paid software from the official website of Lightburn.) supports Windows, Mac OS, and Linux.
NEJE Software Upgrading Service: YES
NEJE Cloud Gallery: YES
NEJE Scanner function: YES
Frame material: CNC Cutting Composite plate, aluminum alloy, acrylic.
Can Engrave： MDF/Balsa/Paper/Wood/Fabric/Plastic/Leather/Plywood/Foam Paper/Anodized Aluminum
Can Not Engrave： Metal/Glass/Stone/Ceramics/PCB/Stainless Steel/Reflective Material/ Transparent Material
Continue working: Unlimited
Wavelength： 450nm
Beam Shape： Dot (Focusable)
Drive: Built-in
Lens Material: D-ZK3
Heatsink Material： Aircraft Aluminum + Brass Shell
Luminous Color： Blue
Input Voltage: AC100-240V, 50/60Hz
Output Voltage: DC12V, 4A
Image Format: .bmp \ .jpg \ .png \ .nc \ .dxf \ etc..
Plug Type: EU / US (Optional)
Features
More Convenient. Off-line and APP Wireless Control. NEJE Scanner Wireless Transfer. Cloud Gallery and Online Gcode Makes Creation Easier.
Professional CNC software: Benbox , LaserGRBL. 170 x 170 mm Engraving Range. Operating System: windows 7/10 / android / iOS / macOS. Picture format: BMP / PNG / JPG / NC / DXF
Greater Power. Faster Speed, More Accurate Precision, If you are a true Maker, DIY Handyman, CNC engineer or an artist, this machine offer a great way to that
Carved more material. It can carve MDF, balsa, paper, wood, fabric, plastic, leather, plywood, foam paper, anodized aluminum, etc.(Not suitable for iron or other metal)
We provided 2-year warranty, and full life customer service. If you have any questions about this engraving machine, please contact us, we will reply to you in 24 hours.
Package Included
1 x NEJE 3 Laser Engraving Machine
1 x N30610 Laser Module
4 x Nuts
1 x Red goggle
1 x L-shaped wrench
1 x USB Cable
1 x Small wrench
1 x 12V4A Power Adapter(Can Note Choose EU US UK Plug)
1 x Small Wooden block
1 x Test Paper
