Package include:
1 x 775 Spindle Motor with ER11 Collet
1 x GRBL control board
10 x 20°0.1mm drill bits
1 x Set of allen wrench
1 x Power Supply
1 x U disk
English manual link will send to your email.
Notice: The machine for a full set of spare parts, shall be installed by the buyers,the package include the U Disk , with detailed user manual and free software,buyers don‘t need to worry about machineAssembly.We suggestcnc-based buyers to buy,This machine is not industrial grade level.
1. CNC 1610 GRBL Control DIY Laser machine 3 Axis
Introduction:
Body usedprofilesand plastic,
small size, light weight, USB interface, GRBL control system, learning,
entry preferred. Can use carving knife, but also can use laser
engraving.
Can be engraved plastic, wood, acrylic, pvc, pcb, wood and the like material.
Specification:
Profile Dimensions: 300x260x250mm
Travel (engraving range): 180x100x45mm
Table size: 180x100mm
Screw: 10mm Dia
Stepper motor: 42 stepper motor
Voltage: current 1.3A, torque 0.3N.m
Spindle: 775 spindle motor (12-36V) 24V: 7000r / min, 36V: 9000r / min
Power: 24V 5A power adapter (input voltage 110-240V), simple and convenient
Gray Part Material: Plastic
Control software: Grbl Controller
Design software: All CAM (computer aided manufacturing) software can be
System requirements: windows XP SP3, win7, win8, win10
Interface: USB
Specification:
Connection: USB (USB-CH340)
Software: GRBL controller, UniversalGcodeSender
Input voltage: 12-36V
Master chip: atmel 328P (arduino nano)
Stepper motor driver: A4988
Spindle drive chip: MOSFET (recommendation 12~36V, current : within 10A )
Spindle PWM speed: Support
Support
stepper motor: 12V, maximum current of 2A or less is recommended within
1.5A and additional heat. (Any stepper motor 42, 57)
Laser engraving: Support
Power Interface: 5.5-2.5mm DC interface
Main application:
Can engrave plastic, wood, acrylic, pvc, pcb, wood and the other similar material.
