1pcs 0501 DSP handle only
Your can use it not connect computer any more, very convenient.
the software and manual (English version) will send online after purchase.
This item we have already set it into English Version, please purchase it with confidence.
0501 DSP controller --Main Information
1. This is the copy one.(need Original RichAuto A11E/A11S? Click here)
2. DSP controller for cnc router,USB connect,can be use without computer
3. suitable for 3 axis
4. Model : 0501
5. We have set up the English version before delivery
6. Manual and software can be sent by mail
|
Contents |
3 axis 0501 CNC DSP control system |
|
Processor |
128M DSP |
|
File Memorizer |
128M memorizer inside, it supports file with any size because of adopting mobile memorize technology |
|
Display |
LCD with 128 dot*64 dot |
|
Communication Terminals |
USB terminal and U Disk |
|
File Format |
G code , PLT files (optional) |
|
Axes |
3 axes |
|
Help Function |
Useful help information and guide |
|
Languages |
Chinese, English, Russia, France, Japanese(optional or customize) |
|
Operating Interface |
Friendly Buttons and Menu Drive |
|
Drive System |
Step Motors |
|
Interpolation function |
linear, curve |
|
Cutter Adjusting function |
Yes |
|
Spindle Control Function |
Yes |
|
System Data Inspect Function |
Yes |
|
Processing Data Inspect Function |
Yes |
|
Processing Position Adjusting Function |
Yes |
|
Multi Working Coordinates |
It has 9 working coordinates |
|
Stop Point Reprocessing Function |
Yes |
|
Copy Processing Function |
Yes |
|
Data protection when power off |
Yes |
|
Working Temperature |
0C to +70C |
|
Humidity |
<90 no dew no frost |
|
Outer Voltage |
5 V |
|
Consumptions |
2 W |
|
Dimensions(mm) |
156*110*38 |
1. Totally independent from PC platform;
2. Directly read files from U Disk;
3. Easily process G code or PLT file with super size;
4. Strong system and process file examining function;
5. Easy to update system program;
6. It supports high micro step which makes precise and fast process possible;
7. Support to process part of the file;
8. Reliable data protection and recover function;
9. Friendly operating interface
Cautions
1. Don't use this product in strong magnetic filed or interfere environments;
2. Don't PnP U Disk while it is running a file;
3. Protect it from water, moist, dust and fire;
4. Protect it from metal materials getting into the cover;
5. Forbad to open the cover, there is no any user maintainable parts inside;
6. Plug U Disk and other lines gentle.
