Display size

10.1" TFT

Display area

222.72mm(W)x125.28mm(H)

Resolution

1024*600 pixel

Display color

16.77M color

Display angle

of view

70/70/60/70(left/right/up/down)

Contrast ratio

500:1

Backlight

LED

Brightness

400cd/m2

Backlight life

More than 30000 hours

Touch Panel

4 wire precision resistance network

 (surface hardness 4H)

Processor

ARM RISC 32Bit 792MHz

Memory

128MB NAND Flash Memor

y+128MB DDR3 Memory

Memory extension

1 USB Host

RTC

Built-in

Printer port

USB Host/Serial port

Ethernet

None

Program download

USB Slave/U disk

COM port

COM0:RS232/RS485/RS422;

COM2:RS232

Electrical specification

Rated power

6W@24V DC

Rated voltage

DC10V～DC28V

Allowable loss

of power

<3ms

Insulation resistance

Greater than 50MΩ@ 500V DC

Hi-pot test

500V AC 1 minute

Structure specification

Shell material

engineering plastic

Dimensions(mm)

280mm*193mm*36mm

Cutout size(mm)

261mm*180mm

Weight

0.9 Kg

Environment specification

Temperature of

working environment

0～50℃

Humidity of

working environment

10～90% non-condensing

Storage environment

temperature

-20～60℃

Storage

environment humidity

10～90% non-condensing

Sine vibration test

10～500Hz, 30m/s2, X, Y, Z direction/ hour

Cooling method

Natural air cooling

Certification

Panel protection grade

Conforming to IP65

certification(4208一93)

CE authentication

Comply with EN61000-6-4:2007+A1:2011,EN61000-6-2:2005

Software

Configuration software

Kinco DTools V3.2 and above version

Dimensions (Unit:mm)
