Hot air 3 zones HT-R490 BGA Rework Station 220V 110V
CE Certification
RE:110V version not have built-in vacuum pump,will send FFQ939 manual vacuum pen in accessory box.
Technical Parameters
Basic Parameters | |
Heating | HR |
Dimension | L580mmx W560mmx H650mm |
Weight | 28kg |
Total weight | About 35 kg, vary with the differen need of the users |
Electrical Parameters | |
Power | 220V AC |
Upper Heating | HR |
Size of upper (IR) | --------------- |
Consumption of upper (IR) | --------------- |
Nozzle of upper(HR) | 4pcs: 19x19, 29x29,34x34,37x37 mm |
Consumption of upper (HR) | 800W |
Bottom Heating | HR |
Nozzle of bottom(HR) | 1 pcs: 50x50 mm |
Consumption of bottom (HR) | 800W |
Bottom Preheat | IR |
Consumption of preheat (IR) | 2400W |
General power | 4KW |
Temperature Control | |
Control mode of Upper | Independent temperature control, high-precision closed-loop |
Control mode of Bottom | Independent temperature control, high-precision closed-loop |
Rework Function | |
SMD | Suit for welding, remove or repair packaged devices |
Size of applicable chips | ≤80mm x80 mm |
Size of applicable PCB | MIN 10mm* 10mm MAX 350mm* 400mm |
Packing list:
1× bga rework station
5× nozzles: 4 pcs top(19,29,34,37mm) and 1 pcs bottom(50mm);
6× pcb jig (with screw)
1x vacuum pen
1× k-type thermocouple
1x socket head wrench
1x Computer Cable
1× CD of manual and software (if not get, may be lost in customs, please contact us)
Optional gift:
1pcs 80/90MM universal jig
10pcs BGA Universal Stencil
Specification for reballing jig
The new self-locking BGA reballing station (patent product)
It is made of Aluminum alloy structure, lightweight and durable structure
We used the old models have such an experience: It is too much trouble to adjust the position of the chips,
need to repeatedly adjust the folder block in order to align the center position, time-consuming and laborious.
This New reballing station is with automatic centering function, rotating spiral disk, four folders block locking chips without a single adjustment,
positioning accuracy standards, clamping speed, high efficiency!
Dimensions: 80mm *80mm and 90mm * 90mm.
Advantages:
1. For both 80mm and 90mm stencils
2. No need use wrench to adjust the height, just use finger up and down
3. Suitable for rectangle chips (picture below), and very small chip, such as 4*4mm
4. High precision for adjusting the chip, magnet inside, auto fix, more fast and convenient .
Simultaneous Adjustment on 4 Sides
Auto Locking
Accurate Position
Easy Operation
Rotator
Compatible with 80mm and 90mm Stencils
Specification for 10pcs BGA Universal Stencil
Detail list:
0.3mm Universal
0.35mm Universal
0.4mm Universal
0.45mm Universal
0.5mm Universal
0.55mm Universal
0.6 mm 0.9 Universal
0.6 mm 1.0 Universal
0.6mm Universal
0.76 mm Universal
