RuoShui 4090A Digital Bench LCR Meter Capacitance Resistance Inductance Measure LCR Digital Bridge Accuracy 0.1% 100hz~10KHZ Bandwidth Desktop Digital LCR Bridge
Description
Test frequency: 100Hz, 120Hz, 200Hz, 400Hz, 800Hz, 1KHz, 2KHz, 4KHz, 8KHz, 10KHz; Testing level: Six fixed level(0.1V, 0.3V, 0.6V, 1V, 1.5V, 2V);
Signal source output impedance: 30Ω , 100Ω; Test Parameter: Principal parameter: L/C/R/Z, Secondary parameter: X/D/Q/θ/ESR
Supporting DC Resistance (DCR) and Electrolytic Capacitance Measurement; Data recording function (maximum, minimum, average);
3.5-inch TFT display, 5-bit display; The basic measurement accuracy is 0.1%; Supporting SCPI Communication Protocol;
Manual and automatic range; With open circuit and short circuit calibration function; Comparator sorting (5 gears), alarm function.
Technical indicators
Display: 3.5 inch TFT LCD, resolution 480 *320, color 16M
Number of display digits: Main parameter: 5 digit, Secondary parameter: 5 digit
Test parameter: Principal parameter: L/C/R/Z，Secondary parameter: X/D/Q/θ/ESR
Measurement Range: L: 0.001μH～9999H; C: 0.001pF～99.999mF; R: 0.0001Ω～99.99MΩ
Measuring display speed: 2 time/s (slow), 4 times/s (medium), 8 time/s (fast)
Internal bias: 0-1500mV adjustable, at a step of 1mV
Signal source output impedance: 30Ω, 100Ω
Calibration function: Open circuit calibration, short circuit calibration
Screening function: The limit range of screening can be set to -50%～＋50%, and the fixed points are 1%, 5%, 10% and 20%
Comparator: 5 groups sorting,3 groups of qualified setting, one group of unqualified setting, one group of auxiliary setting
Interfaces standard: RS232, USB Device, Handler.
Others: Support dc resistance (DCR), electrolytic capacitor measurement model,Adjustment of backlight brightness, Chinese and English are optional.
General specifications
Power supply: 220V.AC±10%, or 110V.AC±10%, 45~65Hz
Power consumption: <10W; Humidity range: 0 ~ 40 C, < 90% relative humidity
Temperature range: Operating state 10℃~+40℃, non-operating state -10℃ ~+60℃
Standard accessories
EU/US/UK power cord; 4-terminals of kelvin testing cable
VICTOR 4090 Series Desktop Digital Bridge Capacitance Resistance Inductance Measure LCR Meter
Standard accessories
1: LCR meter*1pc
2: Kelvin Clip*1set (35A)
3: Power cord *1pc
4: User manul *1pc
Optional accessories (Please contact customer service for price)
RS232 cable or USB cable
handle cable
SMD component test fixture（links to purchase）
