USB 5 Axis Mini CNC Router 3020 3040 3060 6030 Wood Engraving Machine 400W Spindle Motor 3/ 4 Axis PCB Milling Cutting Tools
Technical Parameters
1. Model: 2030 / 3040 / 3060(6030)
2. Effect Stroke: 2030: XYZ axis=180*270*95mm
3040: XYZ axis=290*390*95mm
3060: XYZ axis=290*570*95mm
3. Acceptable material thickness: Max 120mm
4. Repeat positioning Accuracy: 0.02mm
5. Interface: USB port
6. Driver: Toshiba 6560 3A
7. Stepper motor: 57HS56
8. Spindle motor: 400W ER11-3.175mm collet, 0-12000RMP
9. No-load speed: Max 1600mm / min
10. Frame material: Aluminum profile
11. Rail type: XY axis 1605 Ball Screw, Z axis 1204 Ball Screw
12. Software: MACH3 (G-code)
13. Support system: Windows XP, 7,8,10
4th Axis:
Center height: H = 51mm
Chuck: 65mm 3 Jaws
Maximum turning diameter: ≤ 81mm
Deceleration ratio: 4:1
Stepper motor: 57HS56
5th Axis:
The fourth axis gear ratio: 4: 1 (57 two phase 3A stepper motor 1.2N)
The fifth axis reduction ratio: 5: 1 (57 two phase 3A stepper motor 1.2N)
Four jaw chuck 60MM
The clamping: Positive direction: 40mm; In the opposite direction:70mm
Fourth axis Center height: 55MM
The fifth axis higher than the 4th axis 44 mm
Bottom fixed hole distance: 150mm x 85mm
