If you need the Buttons, you could purchase in the link as follow:
https://www.aliexpress.com/item/4000007676737.html This controller could use 5V 4-Pins/6-Pins 100PPR Handwheel Encoder, you could purchase in the link as follow:https://www.aliexpress.com/item/4000008563589.html If you need the Wiring Board, you could purchase in the link as follow:https://www.aliexpress.com/item/4000742074744.html
If you need IO Expansion Board, you could purchase in the link as follow:
https://www.aliexpress.com/item/4000742166700.html
Package Included:
1 x CNC Control System XC809T
1 x Expansion Panel (5 x 22mm holes, 1 x 22mm/44mm holes)
2 x Parallel Female Connectors
2 x Parallel Male Connectors
1 x English Manual (We will send by Email)
Descriptions:
XC809T multi-function lathe CNC system is a new generation CNC system developed by our company. It adopts 32-bit high-performance microprocessor, real-time multi-task control technology and hardware interpolation technology, fully linked, high-speed small line segment look-ahead algorithm. 0.001mm interpolation accuracy, maximum speed 30m/min.
XC809T CNC System Hardware and Software Features:
Based on 32-bit microprocessor, fully linked, 0.001mm interpolation accuracy, maximum speed of 30 m / min, support direction + pulse and quadrature pulse.
With a 7-inch color widescreen LCD, resolution 800X480, Windows interface style. Equipped with 8 soft function keys, the operation is simple and easy to learn. Provide rich display interface such as parameter classification, alarm log, system diagnosis, etc., convenient for debugging and maintenance.
International standard G-commands, compatible with FANUC system commands.
Full-screen editing of the part program, built-in 512M massive program, can store 500 parts program.
With USB interface, support U disk file reading and writing, data backup.
Input 24 (expandable to 96) points, output 24 (expandable to 96) points (custom, flexible and convenient.
Chinese/English operation interface, complete help information, and more convenient operation.
Support knife length tool compensation and radius tool compensation.
Support hand wheel trial processing, convenient program debugging.
Support multi-level operation rights, convenient device management, and limited time system locking.
Support GG, Mastercam, PowerMill, FeatureCAM and other third-party software G code files.
Support self-programming tool magazine, flexible use of a variety of tool magazines, servo turrets.
The two-spindle support spindle 2 synchronizes with the spindle 1 to achieve flying cutter cutting (requires dual servo spindle).
Dual spindle positioning for double-head machining.
Simultaneous operation - a feeding program for efficient machining.
Supports side drilling and tapping spindle 2 position interpolation tapping.
Technical specifications:
Keys instructions
Dimension:
