Affordable Wholesale NEW LY IR6500 V2 BGA Rework Station Infrared IR BGA Machine with Solder Balls Welding Flux Stencils for Mobile Repair

SKU: 32785592677
Safe Payment Guarantee:

LY IR6500 V2 infrared BGA Soldering Rework Station IR 6000 For Motherboard Chip PCB Refurbished Repair System


CE Certification
can be connected to a computer
8 constant temperature segments
It can easily rework the variety of CPU's seat


Notice:Free Tax To Russia ! If no receive the CD , please contact us , we will provide the Link for the downloading the software

BGA Rework Station Introduction

IR6500 V.2 Rework station for laptop motherboards, desktop computer motherboards, server boards, industrial computer boards, all kinds of game boards, communications equipment motherboards, LCD TVs and other large circuit board BGA rework.

The Real Photo Taken by us:


1. USB interface.

2. 2 temperature zones

3. With tempering glass,more uniform heating

4. Hot sale model, praised by many customers.

5. Low cost.

6.  Technical support is always available

7.  Original Factory, look for worldwide distributors


Where this  IR6500 DIY IR BGA Reflow Rework Station Price Good can be used for ?

1. For repairing Mobile phones

2. For repairing Notebooks/ Laptops/computers

3. For repairing game consoles, especially for XBOX360/PS3/WII

4. For repairing any other mainboards with size from 22x22mm to 500x400mm

5. For preheating chips or mainboards before soldering to improve rework efficiency.


Specifications of this  IR6500 DIY IR BGA Reflow Rework Station Price Good

Total power

1250W

Voltage

AC220V±10%     50/60Hz

Top heater

IR 400W

Size of topr heater

80mm*80mm

Bottom heater

IR 800W

Size of bottom heating

180mm*180mm

PCB size

Max. 400*305 mm

BGA chip size

Max. 70*70 mm

Positioning

V-groove PCB

Temperature  control

K Type temperature Sensor and Closed loop

Temperature accuracy

±2°C

Dimension

475*480*420mm

Net weight

16 KG


Main Structure of this IR6500 DIY IR BGA Reflow Rework Station Price Good



Packing list:

1× bga rework station

1× power cable

1× usb to rs232 port cable (with CD)

1× thermocouple

1× vacuuum pen

1x tweezers

6x pcb jig with screw

1× CD of manual and software (if not get or broken, please contact us,we send to you by mail)
