Product Features:
1:Suitable for iPhone 11 Pro Max X XS XSMAX
2:Motherboard detection/Test malfunction/Startup/Display/Touch Camera/Flash/Photosensitive/Handset/Speaker
Online/WiFi/Face recognition, etc.
3:High quality probe.Longer life
4:Clamshell design.Convenient clignment
Operation flow diagram
1.Place the lower motherboard first, pay attention to the three positioning posts on the test frame corresponding to the three screw holes of the lower motherboard
2.Place the test pin board above the lower board. Note that the positioning holes of the test pin board are facing down, the positioning pins of the test pin board are facing up, and the three positioning holes of the upper pin board are corresponding to the positioning pins on the lower board
3.Then place the upper motherboard on top of the test pin board. Note that the three positioning posts on the pin board correspond to the three screw holes on the board.
4.Finally, buckle the test platform, install the SS-905N boot cable, connect the screen, and connect to a regulated power supply or battery to start the test.
5.To test other functions, just connect the cable to the motherboard's corresponding interface with other accessories (recommended to extend the cable)
