NOTE:
(Como os óculos são produtos anti-epidêmicos, a alfândega brasileira não permite produtos com óculos. Os produtos no armazém do Brasil não incluem óculos, obrigado pela compreensão).
DESCRIPTION
NEJE 3 with N30820 module is a portable and safty desktop laser engraving and cutting machine with strong engraving and cutting capabilities. This device is small in size but equipped with almost all professional functions designed by NEJE. Particularly good at engraving hardwood, glass, rubber stamps, cutting materials smaller than 170x170mm, and users who require a portable design is a very good choice. NEJE 3 also has functions such as auto air assist and auto smoke extension. MEMS gyro sensor can also protect safe use.
SPECIFICATION
Model： NEJE 3Control Board: NEJE 3Satety Protection: MEMS Working Size: 170 x 170 mm Pixel: 2266 x 2266 px Dot pitch: 0.075mm 338dpiSoftware: NEJE APP for Android, NEJE 3 APP for iOS / ipadOS / macOS, NEJE Win Software, LaserGRBL，LightBurn.LightBurn ( paid software from the official website of Lightburn.) supports Windows, Mac OS, and Linux.NEJE Software OTA Upgrading Service: YES NEJE Cloud Gallery: YES NEJE Scanner function: YES Frame material: CNC Cutting Composite plate, aluminum alloy, acrylic.Input Voltage: AC100-240V, 50/60Hz Output Voltage: DC12V, 4A Laser: N30820Optical Power: 450nm 5.5W CWContinue working: Unlimited Wavelength： 450nm Beam Shape：focus 0.08x0.08mm DotDrive: Built-inLens Material: D-ZK3
NEJE 3 EXPANSION DESCRIPTION
M7 relay expansion accessories, can be used to control AC or DC power supply smoke exhaust system, can also be used to control other circuits, used as M8, there are safety risks when operating high-voltage circuits, requiring professional operation; M8 valve expansion accessories, can be used To control the air compressor switch, neje 3 supports accessories expansion, but the relay module, air valve module and Door need to be purchased separately, not included in the product list.
About Air Assist
-It is only necessary to add air assist when cutting plywood larger than 3mm and engraving rubber stamps such as carbonized materials. Air assist below 0.4mpa does not make any sense.
About Roller
-Support almost all rollers, round wine bottles, mugs, ceramic mugs can be engraved.
Note (please pay attention)
1. Wear laser goggles during use and avoid touching the laser directly with your eyes and skin!
2. Do not engrave mirror objects, pay attention to fire, pay attention to pets when working!
3. Smoke will be generated when burned, please pay attention to smoke exhaust indoors.
4. The warranty period of the laser module is one year.If you have any quality problems (except individual situation like using the laser module more than 30 minutes per time and cause damage), please feel free to ask our customer service for help.
5. If your laser module has any problems, please do not disassemble it without our permission.It will destroy the laser module.
6. If you have any quality problems about the machine, please feel free to contact us.Many operational issues can be resolved as per your video and problem description.Thanks in advance.
Package Included
1 x NEJE 3 laser engraving machine
1 x laser module (n30820)
4 x Nuts
1 x goggles
1 x L-shaped wrench
1x USB Cable
1 x Small screwdriver
1 x 12v4A power adapter
1x EU adapter
1 x small wooden block
1 x Test Paper
Please, note
If there is a customs point check, customs duties are borne by the customer, hope you can understand.
Do not accept bad reviews and disputes due to tariffs.
