Features:
Small and practical, no problem for using on your desk.
The control system is open source (technology that controls system is provided) for some players who like DIY.
Desktop DIY mini CNC engraving machine for carving and more cost-effective than normal engraving machine.
Support our professional English design software for Win 7, XP, Win 8, Win 10.
500mw / 2500mw / 5500mw optional laser module with heatsink, high laser engraving power and long working time.
180*100*45mm working area, Control Software: GRBL (include ER11 chuck).
Aluminum alloy and nylon material with fine workmanship show excellence in quality.
Very interesting to install and use, perfect gift for engraving DIY enthusiasts.
Wide application: can be used for print, hand tools and industrial processing.
Specifications:
Laser Power: Without Laser / 500mw / 2500mw / 5500mw (Optional)
Material: Nylon + metal
Guide Rail Diameter: 10mm
Stepper Motor: 42 stepper motor 1.3A/0.3N.n
Engraving Area: 18 * 10 * 4.5cm
Table-board Size: 18 * 10cm
Support System: WindowsXP/7
Power Supply: AC110-240V
Control System: GRBL, USB interface
Use Spindle Motor (triaxial engraving):
Spindle Diameter: 45mm
Spindle Rotate Speed: 10000r/min
Spindle:775 spindle motor (12-36V) 24V: 10000r/min
Spindle Chuck: ER11-3.175mm, can change to 0-7mm
Control Software: grblcontrol(Candle)
Supporting File: G-code(nc.txt.tap.gcode...)
Working Accuracy: Approx. 0.2mm
Machinable Material: Wood, plastic, PCB, carbon fiber, acrylic, density board, etc
Use Laser (2-axis plane carving):
Laser Interface: 12V, support PWN
Laser Power: 500mw/2500mw/5500mw
Control Software: laser GRBL
Support File: G-code/picture
Working Accuracy: 0.1mm
Machinable Material: Wood, plastic, leather, paper, etc
I. GRBL 1.1f,USB port cnc engraving machine control board, 3 axis control
Main application:
Can be engraved plastic, wood, acrylic, pvc, pcb, wood and the like material.
