Working Stator 28G 36G line velocity :19m/s 27m/s Laboratory Equipment Digital High disperser Homogenizer AD300L-H 5000-18000rmp
Introduction :
AD300L-H Laboratory High Shear Homogenizer adopts structure compact series-excited type miniature high speed motor drive for the Low to medium and High viscosity liquid mixing , dispersing&Homogenizing materials in liquid medium.
Main Features:
1. High Shear Homogenizer has Various of agitators are designed for different processing capacity
and difference experiment requirement ,include Crushing, emulsifying , Homogenizing , polymerization, suspension, dissolving and Mixing etc.
2. And it is easy to operate and easy to clean, easy to maintenance .
3. Variable Rating Speed Control provide with a high effect.
4. Speed controller adopts IC constant speed control, can instantly to compensate for speed change of the load changes and power supply voltage fluctuation .
5. Digital speed display.
Power Supply : AC 220V 50/60 Hz
Input Power : 510W
Output Power : 300W
Rated Torque : 96.0N. cm
Working form : S1 min(Continuous)
Work head Material :304L stainless steel
Rating Speed Control :Variable
Range of Speed :5000-18000 rpm
Working Stator :28 G 36G
Digital display rotational speed :×10 rpm LED
Timing control range 1-1000 min:
Work head Maximum Torque : 92.0N. cm
Dynamic speed detection function: yes
Speed memory function : yes
Overload protection function : yes
Shape Size 215×310×720 mm
Permission ambient temperature ≤ 40 °C
Permission Relative humidity ≤ 80 %
Weight : 9.7kg
28G
Capacity(H2O) : 90-7000ml
Min./Max. level of liquid : 60/160mm
Max. viscosity : 6000cp
Max. line velocity : 19m/s
Stator diameter : 28mm
Max. temperature : 120 ºC
Length of work head : 240mm
Material of head : SS316L, PTFE
36G
Capacity(H2O) : 150-13000ml
Min./Max. level of liquid : 60/160mm
Max. viscosity : 7000cp
Max. line velocity : 27m/s
Stator diameter : 36mm
Max. temperature : 120 ºC
Length of work head : 240mm
Material of head : SS316L, PTFE
All of our products are shipped from China,We are not responsible for any custom duty or import tax fee , it is buyer’s responsibility.
