24VDC Travel 200mm CNC Plasma Cutting Lifter Z axis 2150mm/min

model:

JYKB-200-DC24V-GD applicable to plasma cutting . the motor inside is dc motor, if need nema23 step motor, please order another link, the price is a little higher.

Packing details:

JYKB-200-DC24V-GD lifting body*1pc

standard small Clamp *1pc

If need ARC torch height controller, click this link to order.

Specifications and features of CNC plasma lifter- Z axis:

Taiwan TBI ball screw

CNC flame and plasma collision avoidance gun function

With plasma positioning micro switch Inside the lifting body

4- pin air plug

The telescopic shaft is optical and the straight sliding block is stable

Shell color: Black (spray)

working speed: 2150mm/min

Working travel: 200mm

Working voltage: DC24V

Load Weight: 10 kg

Clamp gun hole: 20mm-36mm (angle adjustable)

Retractable cover: high temperature resistant material

Size: L 490* W 130* H 80

Mounting hole size length 70*70*70 width 66

Definition of air plug:

1 foot --MOT+; (motor anode)

2 foot --MOT-; (motor cathode)

3 foot --Zero; (location normally open -zero signal output)

4 foot --COM; (location normally open -COM signal output)

Note: the lifting body built-in limit (10A reverse diode) don't need you connection.

Mounting dimension:
