Feature:UI Digital design, mouse operation, humanized designLabeling functions: Point coordinates, cross lines, coordinate systems, text annotationsLength measurement: Line length, line length, curve length, parallel line distance, point line distanceThe center distance: The radius fixed circle, two points setting circle, three points setting circleGeometric measurement: Line length, radius fixed circle, two point fixed circle, three point fixed circle, concentric circlesThe geometric area: Polygon, squareImage fast: Support for 4K static photosVideo: Support 4K videoMeasurement system: S-EYESpecification:Image sensor: SONY IMX 334 FULL HD 4K industrial camera sensor 1/2 inchEffective pixel: 8.0MPPixel size: 2.0*2.0umFrame rate: 4K 30fps@3840*2160Output interface: 4K HDMI, USB (only for USB mouse, can not output the video to the PC), TF cardPower supply: DC-12VThread: C mountSize:75.00*38.80*75.00 MMWeight:0.3kgAccessory:HDMI Cable, DC-12V Power adapter 180X C-MOUNT LensWorking distance: 95mm
Zoom c-mount Lens
0.5X C-mount adapter
Zoom ratios: 6.5:1
Objective Magnification Power by 0.7 - 4.5X(about 10 - 180X on the display)
Size: 180mm(L) * 50mm(DIA)Working distance:145-100mm 300X C-MOUNT LensWorking distance: 95mm
Zoom c-mount Lens
1X C-mount adapter
Zoom ratios: 6.5:1
Objective Magnification Power by 0.7 - 4.5X(about 10 - 300X on the display)
Size: 248mm(L) * 50mm(DIA)Working distance:110-100mm 100X C-MOUNT LensMagnification Power by 0.12 - 2X (about 8X - 100X on the display)Work distance: 100mmVisual field :2.4mm-32mmSize: 115mm(L) * 40mm(DIA)Weight: 210gWorking distance:30-280mm 200X Working distance:100mm -175mm500X Working distance:90mm -110mmConnector:CS C mountZoom:continouasly variable zoomObjective Magnification:0.7X - 5X(about 28 - 200X on the display)/(about 70 - 500X on the display)Eyepiece lens adapter:0.4X/1XFixed position:50mmLocking:0.7X - 5X LockingThread:42mmAuxiliary Objective Lens:0.35X, 0.5X, 2X,1X (optional)Size:132mm(L) * 55mm(DIA) / 175mm(L) * 55mm(DIA) 56 LED Adjustable Compact Microscope Ring LightProvides intense and focused shadow-free illumination56 bright white LED bulbsLighting direction changeableVariable intensity controlIntense and focused shadow-free illumination100,000 hours of lifePower input: 100-240V, 50-60HZ, auto switchingInside diameter of the ring light: 1.0" (27mm)Overall outside diameter: 1.77" (45mm)Working Distance: 27mm-120mm Packing including:
1 x 4K Digital Camera
1 x HDMI Cable
1 x USB Mouse
1 x Power Adapter (EU / UK / AU Adapter for free)
Optional accessories incluede:
1 x C-MOUNT Lens(100X or 180X or 300X 200X or 500x)
1 x 56 LED Adjustable Microscope Ring Light
