Product Description
producing area: chinese mainland
brand: XCMCU
model: XC609M
voltage: 24V
Power mode: direct curren
Introduction
XC609M multi-purpose multi-purpose CNC system for my company developed a new generation of CNC system. Support milling, boring, attack, drilling and automatic feeding. Using 32-bit high-performance microprocessors, the use of real-time multi-task control technology and hardware interpolation technology, full linkage, 0.001mm interpolation accuracy, speed 12 m / min. It is the choice of CNC drilling machine, CNC milling machine, special machine tool, automatic equipment, automatic welding robot, feeding robot, coordinate robot and so on.
Features:
Based on 32-bit microprocessor, full linkage, 0.001 mm interpolation accuracy, and speed is 12 m/ min.
It can run 3 programs at the same time (1 main program,2 sub-programs), convenient processing, feeding, cutting procedures.
Using 3.5-inch color wide-screen LCD, resolution 480X320, fit for Win interface style.
Equipped with 5 soft function keys, easy to learn and operate.Provides rich display interface of the parameter classification, the alarm log, the system diagnosis, facilitating the debugging maintenance.
Standard G instruction, compatible with FANUC system instruction.
40 kinds of G instructions, support drilling cycle, tapping cycle.
Part program full-screen editing, built-in 128M massive program space, can store N parts programs.
With USB interface, support file reading and writing, data backup of USB flash drive.
Input 24 (can be extended to 96) points, output 24 (can be extended to 96) points (user-defined), flexible and convenient.
Chinese/ English operating interface, complete help information, more convenient operation.
The system adopts the acceleration and deceleration control before interpolation.
Support multi-level operation rights, convenient equipment management, time-limited system locking function.
Support third-party software G code files.
Specification:
Control axes number:1 axes; 2 axes; 3 axes; 4 axes; 5 axes; 6 axes(Optional)
Linkage axes number: Full linkage
Simulated spindle:2
Spindle monitoring: Yes
Small instruction unit: 0.001 mm
Maximum instruction:±99999999 x small instruction unit
Fast feed speed:12000 mm/ min
Fast feed rate: F0,25%,50%,100
Cutting feed speed:12000 mm/ min
Feed rate:0 ~ 150%
Electronic gear ratio:1 ~ 65535:1 ~ 65535
Automatic acceleration and deceleration: Yes
Location: G00 (linear interpolation positioning)
Interpolation: straight line (G01), circular arc (G02/ G03/ G12), spiral interpolation
Return reference point: Auto return reference point (G28)
LCD: 3.5 inches TFT LCD screen, resolution 480X320
MDI soft keys: 5
Single step feed: x1, x10, x100
Communication interface: USB interface
External handwheel interface: Yes
I/ O interface:24/24 (can be extended to 96/96)
Pause (second): Yes
Quasi stop status: Yes
Quasi stop: Yes
Storage stroke check: Yes
MDI operation: Yes, support multi-stage operation
Reset: Yes
Jump switch: Yes
Single segment operation: Yes
Program protection switch: Yes
Self-diagnosis function: Yes
Emergency stop: Yes
Power supply: DC24V
Coordinate system: machine tool coordinate system (G53), workpiece coordinate system (G92, G54 ~ G59), local coordinate system (G52), coordinate system plane
Automatic coordinate system setting: Yes
Decimal point input: Yes
Auxiliary function: M2 digit, user-defined M code, manual/MDI/ automatic control spindle forward, reverse, stop;Control coolant start and stop;Control lubrication start and stop, etc.
Main spindle function
Main spindle function: double spindle
Thread tapping: support
Spindle analog output: Yes, double spindle
Cutter function
Cutter function: It supports center-to-center tool setting and three-point circle-to-center tool setting
Cutter compensation memory: -9999.999 ~ 9999.999,99
Cutter compensation: Spindle length compensation
Edit operation
Editing function: Parameters, diagnosis step-by-step input, program editing, MDI multi-segment execution
Storage capacity: 128M
Number of stored programs: N
Display of program name: Chinese, English, digital, combination
Program line lookup: Yes
Skip optional segment: Yes
Program switch: Yes
Display
Display: Chinese, English
Processing time, number of parts display: Yes
Spindle speed, M/ S instruction: Yes
Product connection define and method：
Appearance and size：
Product Package
1 x Control System
4 x Terminal and Screws (set)
