DIY mini cnc wood engraving machine 400w usb milling lathe metal router PCB engraving carving machine ,model: 3020/4020 /6020/ 3040/ 3060 (3axis /4axis 5axis)
Package has CD , CD include detail english manual and software and operate video , it is very easy for operate the machine
Specifications:
Model and Technical Parameters
MODEL | 3020/4020/3040/6020/3060 metal | |||
Attribute | 3axis | 4axis | 5axis | |
Axis | 3axis | 4axis | 5axis | |
Interface | USB Port | USB Port | USB Port | |
Spindle Motor: | 400W | 400W | 400W | |
Weigh 3020 4020 3040 6020 3060 | 22 24 30 27 31 | 26 27 35 31 35 | 29 30 35 33 39 | |
Max. working stroke | XYZ=180*270*95mm(3020) XYZ=180*390*95mm(4020) XYZ=290*390*95mm(3040) XYZ=180*570*95mm(6020) XYZ=290*570*95mm(3060) | |||
Acceptable material thickness | Cnc 3020 is ≤95mm, cnc 4020/6020/3040/3060 is ≤120mm | |||
Rail type | X Y 1605 ball screw, Z 1204 ball screw, 12 mm optical axis | |||
Spindle motor | 400WDC spindle , 0-9000r/min | |||
Collet type | ER11,1/8"(3.175mm) Collet | |||
Stepper motor and drive | 57HS56 | |||
Repeat positioning Accuracy | 0.01mm | |||
Communication interface | USB Port | |||
System requirements | Win-XP / Win 7/ Win 8 /Win10 | |||
Software Co patability | Mach3/Emc2/Kcam, (Type3,Wentai, ArtCAM, coppercam) | |||
Command code | G code/.nc/.ncc/.tab/.txt | |||
4th Axis Description: | Center height: H = 51mm Maximum turning diameter: ≤ 81mm Deceleration ratio: 4:1 Stepper motor: 57HS56 | |||
5th Axis Description: | The fourth axis gear ratio: 4: 1 (57 two phase 3A stepper motor 1.2N) The fifth axis reduction ratio: 5: 1 (57 two phase 3A stepper motor 1.2N) Four jaw chuck 60MM The clamping: Positive direction:40mm; In the opposite direction:70mm Fourth axis Center height: 55MM The fifth axis higher than the 4th axis 44 mm Bottom fixed hole distance: 150mm x 85mm | |||
