Features:
1. Radiating capacity: 50W/℃
2. Small thermolysis water chiller, energy saving, long working life and simple operation;
3. With completed water flow and over high temperature alarm functions;
4. Multiple power specifications; CE. RoHS and REACH approval.
Model | CW-3000AG | CW-3000DG | ||
Voltage | AC 1P 220V | AC 1P 110V | ||
Frequency | 50/60Hz | |||
Current | 0.45A | 0.9A | ||
Machlne power | 0.10kW | |||
Radiating capacity | 50W/℃ | |||
Max. lift | 10M | |||
Max. flow | 10L/min | |||
N.W | 9.5Kgs | |||
G.W | 12Kgs | |||
Protection | Flow alarm | |||
Tank capacity | 8.5 L | |||
Inlet and outlet | OD 10mm barbed connector | Diameter 8mm fast connector | ||
Dimension | 49x27x38cm (L*W*H) | |||
Package dimension | 59 X 39 X 48cm (L*W*H) | |||
