Features:
1) DC24V 2A power supply;
2) 32-bit high-speed floating-point embedded ARM architecture, 128MB Flash, 512K RAM; 6 general-purpose outputs, 12 universal inputs, TTL level;
3) Equipped with 4.3 inch 65K color LCD screen;
4) 4-axis motor control (X, Y for plane motion, Z for rotary knife lift or synchronous double-head motion (double-headed interchangeable models, including single-belt double-head and double-belt double-head models), U for feeding or platform lifting);
5) Support 2 laser control, laser control output voltage 0~5V adjustable, PWM output 0~100K adjustable, duty cycle 0~100% adjustable;
6) Support rotary knife cutting function, with mark positioning cutting function, rotating knife height compensation, pressure stick control;
7) Support track preview, power-off continuous engraving, real-time correction of light intensity and speed during work, rotary engraving, dual platform switching, split feeding, press feeding, automatic blowing, auto focus, foot switch, safety protection, firmware upgrade , processing information statistics and other functions;
