Package Include:
1pcs 4KW 220V Air-cooled Spindle
1pcs 4KW 220V HY Inverter
1set ER20 Collet(1mm,2mm,3mm,4mm,5mm,6mm,7mm,8mm,9mm,10mm,11mm,12mm,13mm)
Parameter:
1. 4kw 220v spindle Feature:
Size: about 88x310mm
Material: Stainless steel jacket, copper coil.
Speed Ways: Through the inverter output voltage and adjust the operating frequency can be achieved 0-18000 stepless
Cooling: Air cooling mode
Power Interface: Optional GX16 waterproof air plug, there are marked 1234,123 were connected to the inverter power supply (U, V, W), 4 connected inverter ground
Power: 4KW
Voltage: 220V -280v(220v or 380v)
Current: 12A
Frequency: 0-300Hz
Speed: 0-18000rpm
Runout off: 0.003-0.005mm
Diameter(mm): 88
Bearing Type: 4 bearing,P4 grade ,2X7005C and 2X7003C P4
Collet: ER20
Clip Knifediameter: 3.175mm,4mm,6mm,8mm,10mm,12.7mm
Air Cooling ER20 collet chunk
Grease Lubrication
2. 4kw 220v VFD Feature:
Type:4kw/220V inverter
Input Voltage:220VAC/50Hz Single phase
Output Voltage:0-220VAC 3-phase
Frequency:0-400Hz
Warranty: 1 year from the date you purchased
3. ER20 Feature:
Model: ER20(13pcs,1mm-13mm)
Run-out tolerance 0.01mm (0.0006")
First class 1065 carbon steel
Hardened & precision ground
Made of high grade specially formulated spring steel.
Hardened and precision ground.
Built in self-Release design and tools will never get stuck in holder.
