HV-4 inch 80mm HV-6 125MM milling machine horizontal vertical indexing table rotary table
divider 6 division head 10 aliquot
Description:
The HV series erecting indexing table (vertical slewing table) is one of the main accessories of the milling machine. It can be used for indexing drilling or milling, circumferential cutting, boring and boring on the milling machine.
The workbench has a 360° engraved line and has a scale ring with a scale of 1' and a vernier ring with a minimum differentiation value of 10". The rotary table has a brake and indexing worm shedding mechanism.
When the HV series vertical turret is in the vertical position, it can be used with the tailstock (special order) for circumferential indexing drilling and milling of more complex workpieces.
the technical description
1. Made of high strength FC30 cast iron
2. Suitable for milling or other special machines for split cutting
3. The new type of spindle locking system is stronger than traditional double-sided plate type, and the cutting is more stable.
4. Can do 360 degrees, turn the handle 4 degrees, the minimum scale is 10 seconds
5. Can be used horizontally and vertically
6. Additional special accessories can be made: honeycomb plate and tailstock
7. Reduction ratio 1:90
Features
• User-Friendly Machine
• Direct and Indirect Dividing
• Professional Precise Division
• 100% Brand New with Good Quality
Package Included :
1 x Head Stock
1 x Tail Stock
1 x 3 Jaw Chuck ( 80mm or 125mm )
