Magnetic pipe semi-automatic flame gas cutting machine pipe gas cutting machine groove
It is convenient to operate the “CG2-11”. It can cut pipes, the diameters of which are above 100mm. It is used in many fields such as ship, mechanism, electric, petroleum industry and so on.This machine is a advanced pipe gas cutter. It has impacted structure, light weight and can cut continuously.
1. Body | 8．Thermal baffle：To prevent heat to diffuse into the inner of machine. |
2 .Cross feeding hand wheel To adjust horizontal position of torch. | |
9.Two-port valve：To adjust the flow. | |
3. Hoses：Connect them to gas distributor. There are three hoses: preheating oxygen hose, fuel gas hose and cutting oxygen hose. | 10.Gas distributor：Gases are: preheating oxygen, fuel gas and cutting oxygen. |
11 Speed regulating knob：Decrease the speed along “10” toward “0” anti-clockwise. | |
4．Torch | |
5. Adjusting hand wheel of torch | 12．Plug seat |
6．Handlebar | 13．Magnetic roller wheel：The two magnetic roller wheels can make the machine walk along pipe wall smoothly. |
7．Reversing switch：To change the direction of machine. “STOP” position is in the middle. |
Specifications
1.Weight(body) | 14.5KG |
2. Machine dimension | 305MMX310MMX180MM |
3. Power source | 220V 50HZ |
4. Cutting speed | 50-750MM/MIN |
5. Cutting thickness | 6-50MM |
6. Groove angle | 0°-45° |
7. Cutting range | ￠＞108MM(The no-seam pipe) |
8) Cutting accuracy | When the machine walks a cycle on pipe, the error is below 0.5mm every 1m circumference. The smoothness of cutting and groove can reach |
9. Adsorption affinity of magnetic roller wheel | Above 50kiograms |
10. Impulse of machine. | When the machine walks up and down, it is below 0.5mm. |
11. Motor | It adopts 70SZ08 servo-motor. 6000r/min, 68W |
Contents of package
1.Standard pack | |
1） Main body | ：1set |
2） Standard torch unit assemblage | ：1set |
3） Connector of torch | ：1set |
4） Tip | ：3pcs |
6) Gas-in connector | ：1set |
7） Electric case and connecting wire | ：1set |
8) Specification sheets and certificate of qualification | ：1 pc each |
9) Safety rope | ：1pc |
10） Safety buckle | ：1pc |
11） fuse(3A) | ：1pc |
