2.2kw Air Cooled Spindle Motor 5.6A ER20 Collets 18000RPM 4 PCS Steel Ball Bearing With Mounting Flange 300HZ for CNC Machine 7005& 7002
Size:267×110×80mm With Mounting Flange
Speed Control Method:Through 3-phase output inverter and adjust the inverter frequency to change the spindle speed.
Cooling:Air cooling
Power:2.2KW (1HP=0.735KW)
Voltage:220V
Current:5.6A
Frequency:0-300Hz
Speed:0-18000rpm
Runout Off:Less than 0.01mm
Bearing type:2×7005 C P4 DT & 2×7002 C P4 DT
Collet:ER20
Cutter Diameter:1mm,2mm,3mm,3.175mm(1/8),4mm,5mm,6mm,6.35mm(1/4),7mm,8mm,9mm,10mm,
11mm,12mm,12.7mm(1/2),13mm
Grease Lubrication
Main Application:Engrave for wood,bamboo,normal PCB,PVC,PMMA,plastic,duotone board(ABS)and etc nonmetal,also can engrave on gold,silver,copper,aluminium,Pb etc soft metal surface working.(Please pay more attention,this is wood working spindle,only can used for wood working and aluminum working,please don't use it for steel.If you need steel working,please check the metal spindle,thank you!)
