Mechanic DX-4K Air 4100W Pixel HDMI Trinocular Microscope HD Camera Industrial Grade Camera For Mobile Phone Motherboard Repair
Features:
4K HD microscope camera, original Sony sensor, 4K video output, 7x zoom, super high-resolution images
Supports up to 518GBTF memory card, SONY CMOS, 1/1.8 4K sensor, 41 million pixels, 7x zoom, supports multiple languages
The video resolution can reach 3840x2160, and the picture resolution can reach 8528x4808PX
Ultra-high-resolution images, high-definition image output, no need to go through the computer host, the general computer display connection can be used
Original Sony sensor, equipped with 4K microscope camera, SONY CMOS, 1/1.84K sensor, high sensitivity, showing rich picture effects
HDMI output: 3840X2160@30FPS(4K); 1080P@120FPS, support 4K video recording
Color processing engine to ensure accurate color reproduction without chromatic aberration
This camera supports inverted microscopes, metallographic microscopes, biological microscopes, polarized light microscopes, manifestation microscopes, fluorescence microscopes, etc.
Specification:
Name: 4K HD Industrial Camera
Model: DX-4K Air
Image sensor: SONY CMOS 1/1.8 IMX334 4K sensor
Video output: 4K/2K/1080P full HD (HDMI output); 4K (USB output)
Sensor size: 1/1.8 inch
Pixel size: 2.0×2.04μm
Resolution: 3840×2160@30FPS(4K); 1920×1080P@60FPS;
Photo resolution: 8528×4808 (41 million pixels)
Video recording: support 4K recording
Product size: 55*45*45mm
Product net weight: 114G
Product gross weight: 397G
USB interface: Type-C USB
USB output resolution: 3840x2160@30FPS; 2592x1944@40FPS; 2592x1944@40FPS; 2084X1536@60FPS; 1920x1080P@60FPS
Spectral response (wavelength): 400nm-1000nm
Timed photo/video: Supports photo/video at the specified time
Dual output: support HDMI and USB output at the same time
Comparison on the same screen: real-time observation and comparison of two products
White balance: support one-key/auto/manual white balance
Image Snapshot: Supports 4K still photos
Sharp interface: standard C/CS interface
Video output interface: HDMI/USB dual interface can output at any time
Storage: TF memory card, maximum capacity of 512G
PC support: support Windows/Mac/Linux system, PC software with measurement function
Back image zoom: 7X times zoom in and out the digital zoom
Image measurement: support HAYEAR software measurement
Language settings: Chinese, English, Japanese, French, German, Russian, Italian, Korean, Turkish, etc.
Working voltage: Type-C 5V /DC12V 1A
HDR function: support HDR, multiple instant HDR, digital overlay HDR
Package includes:
1 x Camera
1 x Remote control
1 x Power adapter
1 x USB power line
1 x HDMI cable
