Provide signal interface
Our marking machine can provide a variety of interfaces, such as PLC, RS232, RS485, etc., which can connect with your equipment or upload data.
This model is Dot Matrix Pneumatic Marking Machine
1. This model can be used for VIN code engraving of trailer, truck or car.
2.This model can be used for steel plate number marking.
3.This model can be used for the engraving of industrial mold number.
4. If you don't know whether this model is suitable for you, please feel free to contact us.
The working video of the marking machine
You can choose this product with different configurations
Section 1：
1:Machine model：CM40150-D
2:Printing range：40*150mm
3:Carving depth： 0.1 to 1 mm (According to the hardness of the material)
4:The customer is required to prepare the air pump.
5:This model has electromagnet to fix the machine.
Section2：
1:Machine model：CM40150
2:Printing range：40*150mm
3:Carving depth： 0.1 to 1 mm (According to the hardness of the material)
4:The customer is required to prepare the air pump.
5:This model has no electromagnet to fix the machine.
Section3：
1:Machine model：CM40150-ND
2:Printing range：40*110mm
3:Carving depth： 0.1 to 1 mm (According to the hardness of the material)
4:The customer is required to prepare the air pump.
5:This model has no electromagnet to fix the machine.
Section4：
1:Machine model：CM40150-HD
2:Printing range：40*60mm / 40*100mm
3:The replacement of short needle is the same as the Section 1.
4:Carving depth： 0.1 to 1 mm (According to the hardness of the material)
5:The customer is required to prepare the air pump.
6:When replacing the short needle, this model has electromagnet to fix the machine.
Section5：
1:Machine model：CM40150-H
2:Printing range：40*60mm / 40*100mm
If the short needle machine is replaced, it is the same as the Section 2.
3:Carving depth： 0.1 to 1 mm (According to the hardness of the material)
4:The customer is required to prepare the air pump.
5:This model has no electromagnet to fix the machine.
Show machine dimensions
（Manual measurement error, for reference only）
MODLE: 40150-D:
SIZE: H=245mm L=315mm W=130mm
MODLE: 40150
SIZE: H=245mm L=260mm W=130mm
MODLE: 40150-ND
SIZE: H=245mm L=260mm W=130mm
MODLE: 40150-HD
SIZE: H=350mm L=315mm W=130mm
MODLE: 40150-H
SIZE: H=350mm L=260mm W=130mm
The following is a multi - Angle photo of the main marking machine
PS:
The picture above shows the four angles of the marking machine.
A:Front view. B:Back view.
C:Right view. D:Left view.
Marking machine interface description
1: A is the control switch of the electromagnet.
2: B is the interface to the host. (link interface H).
3: C is the interface to the air source
4: D is the switch that controls the start of imprinting.
5: E is for the emergency stop switch.
6: F is for the printing needle.
7: G is an electromagnet for fixing the marking machine.
8：J is for the power interface. The voltage is 110V or 220V
9： H Interface of the link coder (link interface B).
10: I is a USB port, you can plug the mouse or USB drive.
Marking machine engraving effect drawing
