1 & DDCSV3.1 3 Axis / 4 Axis Offline Controller

1 & USB Extension Cable & I/O Wiring board

1 &USB Flash Drive

• The DDCS is a 3~4 axes motion controller for stepper and servo systems. DDCS V3.1 is updated from DDCS V2.1 on software and hardware. it combines great power with a tiny footprint and is easy to use.

• The highest output pulse per axis is 500KHz.

• This provides high control precision for stepper motors and servo motors.
  The DDCS numerical control system adopts the ARM+FPGA design framework. ARM controls the human-computer interface and code analysis and the FPGA provides the underlying algo-rithms and creates the control pulse. This guarantees reliable control and easy operation. The internal operating system is Linux based.

• The panel layout structure of the DDCS V3.1 is very rational to save space. All operations are controlled by only 17 keys and a comprehensive G code set is supported.
  The DDCS can be used for many styles and types of CNC machines. Lathes, Routers, Pick&-Place and Mills are just a few examples.

• The DDCS operates as a Stand Alone system without the need of a computer. This guarantees high precision, accuracy and reliability. The interface, even though very comprehensive, can be learned in a very short time.

1.16 photoelectric isolated digital inputs,3 photoelectric isolated digital outputs;

2. 3.1 Version enhanced Algorithm,support soft interpolation,fixed arc interpolation bug of the old version;

3.Analog spindle control 0-10V spindle control (can be modified as PWM output);

4.3-4 axes motor Control.Differential Pulse and direction output signal,Max.500Khz per axis;

5. ARM9 main control chip,FPGA core algorithm chip;

6.5 inches TFT screen, resolution ratio: 480x272,17 operation keys;

7.The Power Supply for the controller is 24VDC, minimum Current is 0.5A;

8.The Power Supply for IO Port is 24VDC,minimum current is 0.5A;By the IO power
supply,system already supply the power for IO ports.So no need the external power supply for IO port anymore;

9.USB flash disk support for G code file input,no size limited of the G-code file ;

10.Support standard MPG;

11.Jog function for each axis (continuous, step, defined distance);Customer can define the distance;

12.Support the operation of quickly specify the running position;

13.Support for “Power Cut” recovery. Data is automatically saved;

14.Backlash compensation, Tool compensation.

1） Control System Unit is compatible with Metric Units and Imperial Units;

2） MPG and extended Keyboard can also control and edit the controller system；
mode” ;

3） Add new function of “Try cutting”(handwheel guiding) and “Single-stage processing
sensor,Rectangular block Sensor;

4） 3 kinds Probing Modes:Fixed Position of tool sensor,Floating Position of the tool

5）Enhanced the software,added a lot of parameters,Optimal Design and algorithm,makes
the new version more strong functions and steady;

6） The Option Language of the system is Chinese/English/Russian.

7) Version 3.1 cited the new circuit design and metal box,which can avoid the noise a lot.
