Application The 5 inch IPS touch screen IP camera tester is designed for maintenance and installation of IP analog, HD coaxial cameras as well as other security equipment. The 1920*1080 resolution enables it to display network HD cameras and analog cameras in high resolution. The unit supports many ONVIF PTZ and analog PTZ control, and cable test functions. CCTV installers often need to carry a variety of testing tools to complete their work. If take the all in one camera tester, making working conditions safer and increasing productivity. CCTV system installation and maintenanceNetwork cabling project installation and maintenanceDome camera, IP TVI CVI AHD SDI 4K H.265 camera testingVideo transmission channel testingPTZ controller Feature ● 5 inch IPS touch screen, 1920x1080 resolution● 8MP CVI/ TVI/ AHD camera test● 8MP EX-SDI, HD-SDI, 3G-SDI camera test● H.265/H.264, 4K video display via mainstream● VGA input, support 2048 x 1152 60FPS● HDMI Input, support 4K 30FPS● DC12V 3A, 48V PoE power output● Rapid ONVIF, Create the test report and modify IP address, etc● Auto HD, auto recognize HD coax camera type and resolution● RJ45 TDR cable test, cable quality test● UTP cable test, detect the near-end, mid-end and far-end fault pointof the network cable crystal head IP Tester Sytem Languages Optional English, Chinese, Korean, Russian, Italian, French, Polish, Spanish, Japanese, Deutsch, Turkish, Portuguese, Czech
