CNC8080 500W Machine
Extraordinary Performance: The central part of this CNC machine is designed with a powerful control board and a NEMA 17 stepper motor, which facilitates users to implement more projects and improve working efficiency significantly.
Powerful Control Box: The front of this concise and compact control box is equipped with a start button, emergency stop button, motor speed control knob, reset and hold button for more agile operation. Supports open source GRBL 1.1 software.
Large Area & Refined Axes: This aluminum-alloy engraving machine has a more extensive engraving range of 32" x 32" x 3.4" / 815 x 815 x 87 mm, which is light and rust-proof. You can also customize other sizes of workbench and laser modules for engraving more materials.
Easy Installation: For your convenience, we have assembled the central part in advance to save your time. With the detailed user manual and assembly instructions, you can complete the assembly in 30-60 minutes.
Extensive Application: Using an offline controller and connecting a computer are two codes to control the machine. It is your ideal option to engrave plastics, soft aluminum, acrylics, PVC, PCB, wood, and many more.
Model: CNC8080
Working Area (X x Y x Z): 32" x 32" x 3.4" / 815 x 815 x 87 mm
Input Power: DC 24V 5A
Stepper Motor: Nema23 57 stepper motor
Spindle: 500W motor, 48V,
Trimmer ：710W
Applies to: Windows, OSX, Linux, and Raspberry Pi
Control Software: CNC-Candle Laser-Lasergrbl/Lightburn
End Mill Diameter: 0.125" / 3.175 mm
Net Weight: 46kg
Product Size (L x W x H): 44.5" x 42" x 15" / 1130 x 1070 x 380 mm
1* 80*80cm Machine
1* control box
