2.2kw Water-cooled spindle kit CNC spindle motor + 2.2KW VFD + 80mm clamp + water pump/pipe +13pcs ER20 for CNC Router
Specification:
1. 2.2kwSpindle Motor:Size: 80mmPower: 2200WVoltage: 220VFrequency: 0-400HzSpeed: 0-24000rpmWater Cooling ER20 colletRunout off: less than 0.005mmGermany SKS 4pcs bearingBearing type: 4pcs bearing C7005X2 C7002X2Grease Lubrication How to connect?The package comes with two Aviation plugs, just put the little one into the spindle, then use the large one to fix the little one, please note the marked number (1.2.3.4) on top of the large one, Pin 1 goes to terminal U on the VFD. Pin 2 goes to terminal V on the VFD. Pin 3 goes to terminal W on the VFD. Pin 4 is a ground/common. 2.Inverter:Input Voltage: 110V/0220V(+/-15%) ,We also stock 380V(+/-15%), please contact usOutput Voltage: 110V/220V ACInput Frequency: 48-63 HzOutput Frequency: 0-400 HzInput Phase: 1 or 3 phaseOutput Phase: 3 phase Note:1.When starting-up the spindle, reference frequency and maximum frequency must be set to 400Hz. Then it can be adjusted to a lower frequency slowly.2.Our standard inverter for this spindle set is YL inverter. If you need HY inverter, please contact the seller before placing an orderVariable Frequency Drive VFD Inverter 2.2KW 3HP 220VAC
1)PID control; advanced calculus PID closed-loop arithmetic, quick responding speed and high suitability;2)Easy PLC function can realize 16 legs of speed and inverter control function;3)RS485 communication port, adopting standard international MODBUS main circuit control;4)With extremely strong anti-jamming capability5)Low output ratting torque0.5HZ-150%, low speed running ability;6)Carrier adjustable by 16KHZ, completely soundless working environment;7)Broad voltage working area, normal running in 304V-456V;8)Auto voltage regulation (AVR) technique, for ensuring the inverter load capability;9)Various control technique by both synchronization and non-synchronization, dynamically realize fast starting without changing brakes;10)With perfect error protection and short circuit starting protection capability; 3.ColletER11size:( 1mm / 1.5mm / 2mm / 2.5mm / 3mm / 3.5mm / 4mm / 4.5mm / 5mm/ 5.5mm / 6mm / 6.5mm / 7mm)ER20Size：(1mm,2mm,3.175mm,4mm,5mm,6mm,7mm,8mm,9mm,10mm,11mm,12.7mm,13mm) 4.Water Pump:Voltage: 220V/110VStructure: Single-stage PumpPressure: High PressureApplication: SubmersibleUsage: Water 5.5M Water Pipes:Size:5M 6mm (ID)*8mm (OD) 6.Spindle Motor Clamp Mount:Diameter: 80mmMaterial: Aluminum,Surface sandblastedApplication: Wood working industry rourter, such as wood door milling engraving and cutting, furniture producing
