Affordable Wholesale HAK31 CNC 6 Station Horizontal Quick Change Tool Post 8 Position NC Electric Lathe Turret With Height 63mm For Machining Center

Empowering Industry – Quality Equipment at Unbeatable Prices!

https://ae01.alicdn.com/kf/H5f63397acc7640bfb6bab317772180cfg/HAK31-CNC-6-Station-Horizontal-Quick-Change-Tool-Post-8-Position-NC-Electric-Lathe-Turret-With.jpg" data-fancybox="gallery">

https://ae01.alicdn.com/kf/H5f63397acc7640bfb6bab317772180cfg/HAK31-CNC-6-Station-Horizontal-Quick-Change-Tool-Post-8-Position-NC-Electric-Lathe-Turret-With.jpg" alt="img">

https://ae01.alicdn.com/kf/H5f63397acc7640bfb6bab317772180cfg/HAK31-CNC-6-Station-Horizontal-Quick-Change-Tool-Post-8-Position-NC-Electric-Lathe-Turret-With.jpg" alt="img">

In Stock

Affordable Wholesale HAK31 CNC 6 Station Horizontal Quick Change Tool Post 8 Position NC Electric Lathe Turret With Height 63mm For Machining Center

SKU: 1005003589462826

Safe Payment Guarantee:

H E N G L I Z I D O N G H U A

Packing Content

1 Pcs HAK31063 6/8 Station NC Turret Toolposts

H E N G L I Z I D O N G H U A

HAK31 NC Turret Toolpost

H E N G L I Z I D O N G H U A

HAK31 Series Size Display

Model/Parameter	A	B	C	D	H1	H2	b1	b	h	L	L1	L2	L3	J	K	M	N	ø	ø1	ø2	ø3
HAK31063	230	205	185	165	63	210	11	20	20	329	55	138	130	25	30	30	30	ø8	ø274	ø318	ø25
HAK31080	260	210	190	180	80	230	11	25	25	350	60	147	130	32	32	32	32	ø8	ø310	ø366	ø25
HAK31100	300	240	220	200	100	260	13	25	25	384	72	164	140	25	40	30	30	ø10	ø360	ø420	ø32
HAK31125	340	288	260	230	125	300	18	32	32	459	85	204	150	32	44	43	43	ø12	ø420	ø490	ø40
HAK31160	460	380	345	306	160	380	22	40	40	564	115	265	160	40	48	56	48	ø22	ø560	ø640	ø50

Unit:mm

Model/Parameter	Center Height	Station Number		Max Tangential Torque	Repeatability Accuracy	Time Of Adjiacent Tool Change And Lock
Model/Parameter	Center Height	Station Number		Max Tangential Torque	Repeatability Accuracy	45°	60°
HAK31063	63	6	8	8500	±2	2.6	2.8
HAK31080	80	6	8	1200	±2	2.8	3.0
HAK1100	100	6	8	2000	±2	3.6	3.8
HAK31125	125	6	8	3000	±2	4.0	4.2
HAK31160	160	6	8	4600	±2	4.3	4.5

HAK31063 8 Positions Allowable Cutting Capacity Diagram

HAK31063 6 Positions Allowable Cutting Capacity Diagram

H E N G L I Z I D O N G H U A

HAK31 Series Structure Diagram

Signalling Wheel
Signalling Disk
Signalling Disk Seat
Driving Seat
Driving Disk Seat
Pin Seat
Pre-indexing Pin
Sleeve
Clutch Disk
Worm Wheel
Clamping Toothed Disk
Outside Toothed Disk
Inside Toothed Disk
Tool Holder Disk
Main Shaft
Tool Position Disk
Housing
Worm
Rear Cover
Motor
Motor Seat

H E N G L I Z I D O N G H U A
