XP3-18R XP3-18T XP3-18RT XINJE Integrator controller OP330 operate panel XC3 PLC new in box
1, package included:
1pcs XP3-18R XP3-18T XP3-18RT integrated OP330 and PLC controller new in box;
1pcs programming cable(Only offer it free when you ask for after order. Not ship it default.
The software is free(we can send it by email if you can’t download it by yourself)
2,
product manual
Integrate PLC and HMI functions (OP330 text display & XC series PLC)
Switch input: 10 points / optocoupler isolation
Switch output: 8 points / (relay output, transistor output, relay transistor mixed output)
LCD display: 192×64 pixels (3.7inh); LCD lifespan can reach 20,000 hours
Up to 26 function keys
The keys are sensitive and precise
HMI and PLC programming use the same programming cable
Waterproof grade meets IP20
Compact structure, greatly saving the space of the electric control cabinet
Naming rules
|
1： |
Series model |
XP series: Display area without touch function |
|
2： |
PLC type |
1：PLC is XC1 series |
|
2：PLC is XC2 series |
||
|
3：PLC is XC3 series |
||
|
3： |
In/out point |
18：10 in 8 out |
|
4： |
Output type |
R:Relay output |
|
T:Transistor output |
||
|
RT: Transistor relay mixed output (the first two transistor outputs) |
||
|
5： |
BD board optional |
B：XP2 series BD board is optional |
|
None：XP2 series can’t extend BD board |
Note: XP1 series do not support extended BD board; XP2 series can be equipped with BD board (differentiated by the model or not); XP3 series can be connected to BD board
Models:
|
XP series |
Output type |
|
||
|
Relay output |
Transistor output |
R&T mixed output |
|
|
|
XP1 |
XP1-18R |
XP1-18T |
- |
|
|
XP2 |
XP2-18R-B |
- |
XP2-18RT-B |
|
|
XP3 |
XP3-18R |
XP3-18T |
XP3-18RT |
|
