Affordable Wholesale 100mm CNC 4th Axis CNC dividing head/Rotation Axis/A axis kit Nema23 for Mini CNC router/engraver woodworking engraving machine

In Stock

SKU: 2011404367

Safe Payment Guarantee:

1 pc-- 4th Axis 100mm 3 Jaw Chuck ( Positive jaw and counter jaw )

The Mach3 system settings: the pulses for 1 required:

( the motor 1 Circle of pulse number × the drive of subdivision number × reduction ratio) ÷ 360 degrees

For example, the two-phase 57 motor, the ubdivision number 16, the reduction ratio 50:1

(200 × 16 × 50) ÷ 360 = 444.44444444)

Ncstudio system settings: the angle of a pulse walking:

360 ÷ (the motor 1 Circle of pulse numberr × × the drive of subdivision number × reduction ratio)

For example: the two-phase 57 motor, the breakdown of the number 16, reduction ratio 50:1

360 ÷ (200 × 16 × 50) = 0.00225

X or Y axis instead of the algorithm is:

Circumference ÷ (the motor 1 Circle of pulse numberr × × the drive of subdivision number × reduction ratio)

Engraving different sizes of round bars, equivalent needs to be set
