Vertical engraving machine cnc milling 3axis can upgrade 4axis 400W spindle
CNC router 1010 engraving machine upright 3axis column type milling machine
Specifications:
Model | Column type 1010-B |
Product size | 400(H)X350(L)X350(W) mm |
Effective work area | 100x100x40mm |
Precision ball screw | 1204 |
XYZ rail material | Hard chrome shaft |
XY rail diameter | 12mm |
Z rail diameter | 12mm |
Repeat positioning accuracy | 0.01mm |
Working precision | 0.02mm |
Processing speed | 0-4000 mm/Min |
Spindle power | 400 W spindle |
Input Power | 220V / 110V power supply |
Drive motor | 42*48 stepper motors (two-phase 4 wire) |
Net Weight | 12kg |
Gross Weight | 15kg |
Outside packing | 50*50*55 (cm) |
Model | Column type 1010 frame |
Product size | 400(H)X350(L)X350(W) mm |
Effective work area | 100x100x40mm |
Precision ball screw | 1204 |
XYZ rail material | Hard chrome shaft |
XY rail diameter | 12mm |
Z rail diameter | 12mm |
Repeat positioning accuracy | 0.01mm |
Working precision | 0.02mm |
Processing speed | 0-4000 mm/Min |
Spindle power | 400 W spindle |
Input Power | 220V / 110V power supply |
Drive motor | 42*48 stepper motors (two-phase 4 wire) |
Net Weight | 8kg |
Gross Weight | 10kg |
Outside packing | 50*50*55 (cm) |
Features:
1. Integrated high-speed microcomputer intelligent control chip, can be equipped with external LCD monitor with hands, automatic detection of computer controlled automatic shield handle motion control functions, can simultaneously track digital recording of computer data and handle mobile data control
2. The computer keeps track of the path, you can run once the computer processing of the data record-keeping process automatically repeats offline processing operation.
3. Manually move the processing to save recorded track record, manually move the machine data and automatically reprocessed run manually move the path.
4. Manual data input processing path and enter the path to run automatically.
5 You can automatically complete the XYZ axis or Z axis of the knife, without complicated computer software operation control
6. Max 5A stepper motor drive current, eight-speed adjustable.
7. Up to 16 segments, higher accuracy, run more smoothly.
8. Overload over-current over-temperature protection function, automatic semi-flow control, fully protect your computer and peripherals.
9. Bipolar constant current chopper drive motor low-speed non-creeping phenomenon, noise, non-resonant region.
10. Closed optical isolation, dual-stage signal processing, and fully protect your computers and devices.
Why buy from us :
Ø CE approved.
Ø Video support.
Ø English manual available.
Ø Mach 3 software send with the machine as a CD.
Ø Can engrave material which hardness below 45.
Easy operating:
Ø Integrated high-speed micro computer intelligent control chip.
Ø With external digital LCD monitor and handwheel controller.
Ø The working process can be tracked, recorded in the digital LCD monitor automatically.
Ø Mach 3 software
Ø Built in frequencey converter and without controller box.
Higher precision because:
Ø Cross slippery platform design rather than gantry design.
Ø Aluminum base sheet is heavy which can make sure no vibration when work.
Ø With auto-checking function.
Ø Ball screw
This Outer box is optional :
