Affordable Wholesale NEW! 4th Axis 3/4Jaw 100mm 4.5Nm NEMA34 86HS45N & HBS86H Closed Loop Stepper Motor CNC Dividing Head Rotation Axis A axis Kit

SKU: 1005004251474533
Safe Payment Guarantee:


1pcs-4th Axis 100mm 3 Jaw / 4 Jaw chuck 3:1 / 4:1

( positive jaw and counter jaw) (& Closed Loop Stepper Motor 86HS45N)

1pcs- HBS86H Hybrid Step-Servo Driver



100mm 3 jaws / 4 jaws self-centering handle

Center height 65mm

Total height, 115 MM

Angle, 1.8 degrees / step

Reduction ratio: 3:1 / 4:1 (synchronous deceleration mode)

Magnetic stepper motor: Nema34 Closed Loop Stepper Motor 86HBS45N 4.5N.m




The Mach3 system settings:  the pulses for 1  required:

( the motor 1 Circle of pulse number × the drive of subdivision number × reduction ratio) ÷ 360 degrees

For example, the two-phase 57 motor, the ubdivision number 16, the reduction ratio 50:1

                      (200 × 16 × 50) ÷ 360 = 444.44444444)


Ncstudio system settings: the angle of a pulse walking:

 360 ÷ (the motor 1 Circle of pulse numberr × × the drive of subdivision number × reduction ratio)

For example: the two-phase 57 motor, the breakdown of the number 16, reduction ratio 50:1

                      360 ÷ (200 × 16 × 50) = 0.00225


X or Y axis instead of the algorithm is:

Circumference ÷ (the motor 1 Circle of pulse numberr × × the drive of subdivision number × reduction ratio)

Engraving different sizes of round bars, equivalent needs to be set







Current / Phase : 6A

Holding Torque : 4.5N.m

DC Resistance : 0.35Ω±10%

Inertia : 1.4KG.CM2

Inductance / Phase : 5.9MH±20%

Weight : 4.0KGS

Step Angle : 1.8°

Position Accuracy : 1.8°±0.09°





1.Without losing step,high accuracy in positioning

2.100%rated output torque

3.Small vibration,Smooth and reliable moving at low speed

4.Compatible with 1000 lines encoder

5.Over current,over voltage and over position error protection





1.Short cylindrical center mounting.

2.Model K11/K12 chucks are provided with one-piece.Jaws(which include a set of intermal jaw and a set of external ones).

3.The jaws for K11A/K12A ,K11C/K12C and K11D/K12D chuck are composed of two-piece jaws. They can perfrom as either internal jaws through adjustment.

4.The jaws for K11A/K12A and K11D/K12D chucks conform to ISO3442 standard.

5.Model K11/K12 chucks are supplied with traditional two-piece jaws.

6.We can provide all kinds of soft jaws.

7.As requested, we can provide chucks mounted from front.





Input voltage: 18-80VAC (50V typical)

Continuous current: 7.5A 20KHz PWM

Maximum pulse frequency: 200K

The default communication rate: 57.6Kbps




1. No step loss, precise positioning

2. 100% rated torque drive motor

3. Variable current control technology, high current efficiency

4. Low vibration, stable operation at low speed

5. Built-in acceleration and deceleration control to improve the smoothness of start and stop

6. User can customize segmentation

7. Compatible with 1000-line and 2500-line encoders

8. Over current protection, over voltage protection, over-tolerance protection

9. Green light means running, red light means protection or offline




(1) t1: ENA (enable signal) should be DIR at least 5μs ahead of time, confirm
Is high. Generally, it is recommended that ENA+ and ENA- be left floating.

(2) t2: DIR is at least 6μs ahead of the PUL counting edge to determine its status
High or low.

(3) t3: The pulse width is not less than 2.5μs.

(4) t4: The low-level width is not less than 2.5μs.






Main application fields:

Advertising industry, Engraving, packaging, lasers, electron industry, medical industry, Printing industry, woodworking, machinery industry, Ceramic Industry, stone industry and so on.





11.1 The power light does not light up

Input power failure, please check the power circuit. Is the voltage too low



11.2 The red light will alarm after power-on

Check whether the motor feedback signal line and the motor power phase line are connected

Step by step, whether the input power voltage of the servo drive is too high or too low



11.3 The red light will alarm after running and rotating a small angle

Whether the phase sequence of the motor's phase line is correctly connected. Incorrect, please refer to the motor identification

Corresponding phase sequence connection with the driver

In the drive configuration parameters, whether the line number of the motor encoder is the same as that of the connected motor

The actual parameters are the same. Reset if different

Whether the pulse input speed is greater than the rated motor's rated position

11.4 No rotation after pulse input

Whether the wiring of the pulse input terminal of the servo drive is reliable

Whether the input mode in the step-by-step servo drive system configuration is pulse input

Related input methods

Whether the motor can be released
