Technical data | |
Model | BNTP69 |
Brand | BNTFLEX |
Product Name | Hose Crimping Machine |
Crimp Force(KN/Ton) | 5000/500 |
Hose Capacity | 1/4" - 2" (4 wire) |
Standard Die Sets Supplied With Machine | 1/4″ – 2″, 10sets |
Max. Crimp Range | 87mm |
Opening | +30mm |
Opening Without Dies | 114m |
Close Speed (mm/sec.) | 6s |
Crimp Speed (mm/sec.) | 2.3 |
Open Speed (mm/sec.) | 8.2s |
Voltage | 220V/380V |
Power | 3KW |
Drive | Electric |
L x W x H Machine (mm) | 850*620*1200mm |
Weight | 320kg |
Hose Crimping MachineBNTP69 Dies | ||
NO.(mm) | Crimp Range(mm) | Length(mm) |
15 | 15-19 | 60 |
19 | 19-23 | 60 |
23 | 23-26 | 60 |
26 | 26-31 | 60 |
31 | 31-36 | 70 |
36 | 36-41 | 70 |
41 | 41-47 | 70 |
47 | 47-55 | 80 |
55 | 55-60 | 80 |
60 | 60-63 | 80 |
Hose crimping machine mainly by withholding mechanism, motor, gear pumps,
control valves and tank components. Suitable for mechanical engineering in the
high-pressure hose assembly with hold processing, but also with hold two-way
elbow, elbow and large shaped head. Hose crimping machine is a metal fitting
through the hydraulic machinery and the corresponding mold with a high pressure
hose withhold closely together to prepare a high-pressure hose and fluid connectors,
referred to as high-pressure hose assembly. High-pressure hose assemblies are widely
used in oil, coal, aerospace, construction machinery, agricultural machinery and other
industries etc.
2016 BARNETT BNT65 High Pressure Hydraulic Hose Crimping machine in ChinaMain Features:
1) Simple structure in linear type ,easy in installation and maintation.
2) Adopting advanced world famous brand components in hydraulic parts ,
electric parts and operation parts.
3) Button way, foot pedal to control the die opening and closing.
4) Running in a high speed,no pollution.
5)Hose Crimping Machine can Crimp the Hydraulic Hoses up to 51 mm /
2 inch Diameter.
6)It is easy to operate with Manual Operation.
Main Features:
Name: our factory
Brand: BNT
Original: China
Our comany is specializing in producing hose crimping machine,hose cutting
machine,hose skiving machine,High pressure hose,Hydraulic hose,SEA&DIN
Series,Teflon hose,Nylon hose,Steam Hose,Industrial hose,Concrete hose,
Drilling hose,Rotrary hose,Air hose,Water hose,Oxygen hose,Metal hose,
Fir proof hose,Hose ferrule,hose fitting,hose Assembly parts,etc.
Main Features:
Name: our factory
Brand: BNT
Original: China
Our comany is specializing in producing hose crimping machine,hose cutting
machine,hose skiving machine,High pressure hose,Hydraulic hose,SEA&DIN
Series,Teflon hose,Nylon hose,Steam Hose,Industrial hose,Concrete hose,Drilling
hose,Rotrary hose,Air hose,Water hose,Oxygen hose,Metal hose,Fir proof hose,
Hose ferrule,hose fitting,hose Assembly parts,etc.
Machine Parts:
Name: our factory
Brand: BNT
Original: China
Our comany is specializing in producing hose crimping machine,hose cutting
machine,hose skiving machine,High pressure hose,Hydraulic hose,SEA&DIN
Series,Teflon hose,Nylon hose,Steam Hose,Industrial hose,Concrete hose,
Drilling hose,Rotrary hose,Air hose,Water hose,Oxygen hose,Metal hose,Fir
proof hose,Hose ferrule,hose fitting,hose Assembly parts,etc.
Main Features:
Name: our factory
Brand: BNT
Original: China
Our comany is specializing in producing hose crimping machine,hose cutting
machine,hose skiving machine,High pressure hose,Hydraulic hose,SEA&DIN
Series,Teflon hose,Nylon hose,Steam Hose,Industrial hose,Concrete hose,
Drilling hose,Rotrary hose,Air hose,Water hose,Oxygen hose,Metal hose,
Fir proof hose,Hose ferrule,hose fitting,hose
Assembly parts,etc.
Pre-Sales Service:
* Inquiry and consulting support.
* Sample testing support.
* View our Factory.
After-Sales Service:
* Training how to instal the machine, training how to use the machine.
* Engineers available to service machinery overseas.
