CNC Breakout Board Mach3 Motion Controller Card USB Ethernet 3/4/6 Axis 2000KHZ for CNC Metal Engraving Milling Carving Machine
Specification:
I. Description:
This is the latest generation motion control card, It could work under Mach3 software.
The maximum step-pulse frequency is 2000 KHz.
II. Features for USB Motion Card:
1.Dual-Processors, ARM+FPGA, More processing power
2.Support all versions of Mach3.
3.Work under Windows 32-bit operating system (not including Mac OS)
4.Support spindle speed feedback function.
5.USB jack does not need to install the driver, plug and play under all versions of Windows.
6.Full support USB hot-swappable, USB connection status monitoring at any time. Under Mach3 working state, USB cable unplugs and then plugs in, but also the normal connection.
7.Supports 3/4/6-axis linkage.
8.Maximum step-pulse frequency is 2000 KHz, can connect servo driver and stepper driver.
9.The indicator light indicates various working status, such as USB connection, Mach3 connection and so on.
10.16 input IO, 8 output IO, Supports extended I / O control.
11.Onboard isolated power supply, not need external power supply.
12.All IO port fully isolated, strong anti-interference, stable performance.
13.Support spindle speed PWM output; support spindle pulse and direction output; support spindle speed output from 0 to 10V analog voltage.
14.Support XHC series of wireless electronic Mach4 MPG
15.With an aluminum shell, effectively shielding interference, stable and reliable performance.
III. Features for Ethernet Motion Card:
Fully supporting all Mach3 versions, support Windows 7, 8, 10 (32-bits);
Only support Ethernet interface, need to set IP address (Please read page 20 on the instruction);
Support save data when power off, support resume from breakpoint;
Support spindle speed feedback;
Supports spindle PWM speed control output;
Support 10 meters Ethernet interface cable;
No need to install the driver, plug and play;
Supports 3/4/6-axis linkage;
Maximum step-pulse frequency is 2000KHz, 16 general-purpose input,8 output;
Support differential signal output;
Velocity feedback function, Spindle speed display in
real time all IO-port isolation, interference, stable performance;
Support controlling servo motor and step motor;
