Disassembled DIY Wood CNC Router Engraver 3020 300W 400W Spindle Motor 2.5W Laser Cutting Marking Machine Kit 220V 110V
2.5W laser for Optional.
DESCRIPTION |
|||
Product package |
No Motor |
300W Motor |
400W Motor |
Operating Voltage |
AC220V/110V |
AC220V/110V |
AC220V/110V |
Spindle power |
None (not including spindle) |
300W |
400W |
Spindle speed |
NONE |
0-8000rpm/min |
0-8000rpm/min |
Chuck model |
NONE |
ER11-3.175mm |
ER11-3.175mm |
cooling system |
NONE |
Strong cooling air |
Strong cooling air |
Driver |
DRV8825 (32 subdivisions) |
DRV8825 (32 subdivisions) |
DRV8825 (32 subdivisions) |
Motherboard |
LEKN(C1)V2.4 |
LEKN(C1)V2.4 |
LEKN(C1)V2.4 |
Communication Interface |
USB communication |
USB communication |
USB communication |
Support system |
XP、WIN7/8/10 |
XP、WIN7/8/10 |
XP、WIN7/8/10 |
Positioning accuracy |
0.05mm |
0.05mm |
0.05mm |
Precision |
0.1mm |
0.1mm |
0.1mm |
Processing stroke |
300*200mm |
300*200mm |
300*200mm |
Workpiece height |
80mm |
80mm |
80mm |
Dimensions |
520*380mm |
520*380mm |
520*380mm |
Package dimensions |
600*350*250mm--18KG (shipped in loose |
||
Processing material |
Wood, acrylic, PVC, nylon, epoxy resin, |
