Product Specification
Model: NEJE 3 B30635
Optical Power: 405nm 500mw
Control Board: 2 x MCU + Wireless control + MEMS
Satety Protection: MEMS
Working Size: 170 x 170 mm
Pixel: 2266 x 2266 px
Dot pitch: 0.075mm
Software: NEJE APP for Android, NEJE Wireless APP for iOS / macOS, NEJE software for windows, Benbox, LaserGRBL with firmware GRBL1.1f.,LightBurn Software with firmware GRBL1.1f.
LightBurn ( paid software from the official website of Lightburn.) supports Windows, Mac OS, and Linux.
NEJE Software Upgrading Service: YES
NEJE Cloud Gallery: YES
NEJE Scanner function: YES
Frame material: CNC Cutting Composite plate, aluminum alloy, acrylic.
Can Engrave: MDF/Balsa/Paper/Wood/Fabric/Plastic/Leather/Plywood/Foam Paper/Anodized Aluminum
Can Not Engrave: Metal/Glass/Stone/Ceramics/PCB/Stainless Steel/Reflective Material/ Transparent Material
Continue working: Unlimited
Wavelength: 405nm
Beam Shape: Dot (Focusable)
Drive: Built-in
Lens Material: D-ZK3
Heatsink Material: Aircraft Aluminum + Brass Shell
Luminous Color: Blue
Input Voltage: AC100-240V, 50/60Hz
Output Voltage: DC12V, 4A
Image Format: .bmp \ .jpg \ .png \ .nc \ .dxf \ etc..
Plug Type: EU / US (Optional)
Features
More Convenient. Off-line and APP Wireless Control. NEJE Scanner Wireless Transfer. Cloud Gallery and Online Gcode Makes Creation Easier.
Professional CNC software: Benbox , LaserGRBL. 170 x 170 mm Engraving Range. Operating System: windows 7/10 / android / iOS / macOS. Picture format: BMP / PNG / JPG / NC / DXF
Greater Power. Faster Speed, More Accurate Precision, If you are a true Maker, DIY Handyman, CNC engineer or an artist, this machine offer a great way to that
Carved more material. It can carve MDF, balsa, paper, wood, fabric, plastic, leather, plywood, foam paper, anodized aluminum, etc.(Not suitable for iron or other metal)
FEATURE
NEJE B30635 is a module specially designed by NEJE for the engraving of miniature wooden handicrafts. It is the 405nm module with the highest power and the smallest light spot. The 405nm module has very high material absorption efficiency, which is higher than that of the conventional 450nm wavelength module. Better material absorption efficiency. Under extremely low pulse power, the material can also engrave accurate grayscale effects. If you have requirements for grayscale engraving of wood products or paper products, this module is the best choice.
Package List
1 * NEJE 3 Laser Engraving Machine
1 * B30635 Laser Module
4 * Nuts
1 * goggle
1 * L-shaped wrench
1 * USB Cable
1 * Small wrench
1 * 12V4A Power Adapter
1 * Eu adapter
1 * Small Wooden block
1 * Test Paper
