YIHUA 853AAA 3 in 1 digital SMD soldering desoldering hot air gun preheat BGA rework soldering station
Feature:
1.Using microcomputer processor PID programmable temperature control technology.
2.Preheating station is to use a glaze layer having a high thermal effect, good thermal shock resistance of the ceramic as the substrate, high-quality nickel branded alloy wire once sintering.It has a high thermal effect, overall good, good thermal stability, uniform heating, high dielectric strength, clean, easy to install and so on features.
3.Air Gun heater use ceramic heater.heating elements firmly wrapped around the model ceramic, rapid and uniform heating.Use the upgraded version fan, the airflow larger than the ordinary fan, spiral out of the wind, long life.
4.Soldering iron part using Imported heater.heating up rapidly, temperature stability, long service life; antistatic design to prevent electrostatic damag to delicate SMD components.
5.The machine has a self-test function.full intelligent over-temperature, short-circuit, open circuit, overload and fault display and protection functions.
6.853AAA preheating station using the user-friendly design.the cover affixed with a high-temperature, insulated protection pads to prevent scalding operation.Uses magnetic induction technology.Card board bracket to prevent protective pads suck hood above.Can rotate 360 degrees, flexible card board.It is suitable for the circuit boards of different shapes and sizes.
7.853AAA temperature correction function Adapt to the environmental impact, or replace the heating elements, soldering iron tips etc. spare parts caused by temperature deviation,can use this function calibration temperature.The correction temperaturerange is -50 °C ~ +50 °C.
8.853AAA has Celsius / Fahrenheit temperature display function Meet different market needs to design the temperature display mode, you can choose under customary interest.
9. 853AAA hot air gun part have add to auto./manual function .
Data:
Input Voltage: AC 110~127V 60Hz/ 220~240V 50Hz
Max power consumption: 1200W
Preheating Station
Temperature Range: 50 ~ 400 °C
Temperature Stability ±2 °C
Display Type: LED
Preheat Area: 120*120mm
Hot Air Station
Airflow type brushless fan spiral out wind
Air Flow ≤120L/min
Temperature Range 100 ~ 480 °C
Temperature Stability ±1 °C
Display Type: LED
Handle cable length ≥100cm
Soldering Iron Station
Temperature Range 200 ~ 480 °C
Soldering iron heater: 60W ceramic heater
Temperature Stability ±1 °C
Tip of ground voltage <2mV
Tip ground impedance <2 ohm
Display Type: LED
Handle cable length ≥100cm
General Usage
1). Suitable for de-soldering and soldering BGA, SOIC, CHIP, QFP, PLCC package SMD IC, Particularly suitable for de-soldering BGA module, computer motherboard north and south bridge, all kinds of mobile phone motherboard SMT IC and LED lights.
2). Shrinking, Paint drying, adhesive removal, thawing, warming, Plastic welding etc.
