If you need the Buttons , you could purchase in the link as follow:
https://www.aliexpress.com/item/4000007676737.html This controller could use 5V 4-Pins/6-Pins 100PPR Handwheel Encoder , you could purchase in the link as follow:
https://www.aliexpress.com/item/4000008563589.html If you need the Wiring Board , you could purchase in the link as follow:
https://www.aliexpress.com/item/4000742074744.html
If you need IO Expansion Board , you could purchase in the link as follow:
https://www.aliexpress.com/item/4000742166700.html Package Included: 1 x CNC Control System XC809M 1 x Expansion Panel (5 x 22mm holes, 1 x 22mm/44mm hole) 2 x Parallel Female Connectors 2 x Parallel Male Connectors 1 x English Manual (We will send by Email) Description: XC809M drilling and attacking multi-function CNC system is a new generation CNC system developed by our company. Supports boring, tapping, drilling and automatic feeding. It adopts 32-bit high-performance microprocessor, real-time multi-task control technology and hardware interpolation technology, fully linked, 0.001mm interpolation precision, and the highest speed is 30m/min. It is the best choice for CNC drilling machines, special machine tools, automation equipment, feeding robots, etc.
Comparison of XC709D, XC709M, XC809D, XC809M:
|
Model |
XC709D |
XC809D |
XC709M |
XC809M |
|
Application Field |
Used in engraving machines, engraving and milling machines, small machining centers |
Used for drilling, tapping, and automated drilling machines. |
||
|
Algorithm |
Micro line segments Look-ahead Algorithm |
General algorithm |
||
|
Workpiece |
Processing standard Workpiece |
Processing non-standard Workpiece |
||
|
Manual Programming |
Support |
Don't support |
||
|
Program exported from Computer |
Support |
Support |
||
-
Based on 32-bit microprocessor, fully linked, 0.001mm interpolation accuracy, maximum speed of 30 m / min, support direction + pulse and quadrature pulse.
-
7-inch color widescreen LCD, resolution 800X480, Windows interface style. Equipped with 8 soft function keys, the operation is simple and easy to learn. Provide rich display interface such as parameter classification, alarm log, system diagnosis, etc., convenient for debugging and maintenance.
-
It can run 3 programs (1 main program and 2 sub-programs) at the same time, which is convenient for writing programs for processing, loading and blanking.
-
International standard G directive, compatible with FANUC system directives.
-
40 kinds of G-command support drilling cycle and tapping cycle.
-
Part program full-screen editing, built-in 512M massive program space, can store N parts program.
-
USB interface, support U disk file reading and writing, data backup.
-
Input 24 points (expandable to 96), output 24 points (expandable to 96) (custom), flexible and convenient.
-
Chinese/English operation interface, switchable, complete help information, and more convenient operation.
-
System uses pre-interpolation acceleration and deceleration control.
-
Support multi-level operation authority, convenient device management, and limited time system locking function.
-
Support GG, Mastercam, PowerMill, FeatureCAM, ArtCAM, JDPaint, Wentai and other third-party software G code files.
-
Supports self-programming of the tool magazine and flexible use of multiple tool magazines.
|
Basic Functions |
|
|
Number of control axis |
1~6 axis (X, Y, Z, A, B, C) |
|
Number of linkage axis |
full linkage |
|
Tool magazine |
Support, need to edit the magazine code |
|
Spindle |
2 analog spindles, where the spindle 1 can use a digital spindle (occupying a digital axis) |
|
Spindle monitoring |
Yes |
|
Minimum command unit |
0.001 mm |
|
Maximum command value |
±99999999 × minimum command unit |
|
Rapid feed rate |
30000 mm / min |
|
Rapid feedrate override |
F0, 25%, 50%, 75%, 100% |
|
Pulse mode |
1: direction + pulse 2: quadrature pulse (if the driver supports, recommended, anti-interference is stronger) |
|
Maximum frequency |
100 KHz, 200 KHz, 500 KHz can be set. (500 KHz can only be realized in all axes orthogonal output mode) |
|
Feed rate override |
0~150% |
|
Electronic gear ratio |
1 ~ 65535: 1 ~ 65535 |
|
Automatic acceleration and deceleration |
Yes |
|
Positioning |
G00 (linear interpolation positioning) |
|
Interpolation |
straight line (G01), arc (G02/G03/G12), helical interpolation |
|
Return to reference point |
Automatically return to reference point (G28) |
|
LCD |
7-inch TFT LCD screen with resolution of 800×480 |
|
MDI software key |
8 |
|
Single step to |
x1, x10, x100 |
|
Communication interface |
U disk interface |
|
External hand wheel interface |
Yes |
|
I/O interface |
24/24 (expandable to 96/96) |
|
Pause (seconds) |
Yes |
|
Quasi-stop state |
Yes |
|
Quasi-stop |
Yes |
|
Storage trip check |
Yes |
|
MDI operation |
Yes, support multi-segment operation |
|
Reset |
Yes |
|
Jump switch |
Yes |
|
Single-segment operation |
Yes |
|
Program protection switch |
Yes |
|
Self-diagnostic function |
Yes |
|
Emergency stop |
Yes |
|
Power |
Single Phase Input 100~240V AC 1.52A 50/60 Hz±1, Output 24V DC 3.2A |
|
Coordinate system |
Machine coordinate system (G53), workpiece coordinate system (G92, G54～G59), local coordinate system (G52), coordinate system plane designation |
|
Automatic coordinate system setting |
Yes |
|
Decimal point input |
Yes |
|
Auxiliary Function |
|
|
Auxiliary function |
M2 digits, M code customization, manual / MDI / automatic mode control spindle forward rotation, reverse rotation, stop; control coolant start and stop; control lubrication start and stop, etc. |
|
Spindle Function |
|
|
Spindle function |
double spindles |
|
Digital spindle |
Supported by spindle 1, occupies one digital axis (Z axis does not support), and the rotation speed is more stable. |
|
Tapping |
Support |
|
Spindle analog output |
Yes, dual spindles |
|
Knife Function |
|
|
Tool function |
Support automatic tool change, support split centering knife, 3-point centering tool |
|
Tool compensation memory |
-9999.999~9999.999, 99 |
|
Tool compensation |
Length compensation for each axis |
|
Editing Operation |
|
|
Editing functions |
parameters, diagnostic bitwise input, program editing, MDI multi-block execution |
|
Storage capacity |
512M |
|
Number of stored programs |
N one |
|
Display of program name |
Chinese, English, numbers, combination |
|
Program line lookup |
Yes |
|
Skip the optional block |
Yes |
|
Program switch |
Yes |
|
Display |
|
|
Display |
Chinese, English, Switchable |
|
Processing time, number of parts display |
Yes |
|
Spindle speed, M/S command |
Yes |
|
Dimensions (mm) |
Dimensions (height × width × thickness) 390×253×80 |
|
Opening size (height x width) |
370×228 |
