Engraving machine DIY CNC 3020 metal CNC Router /Engraving Drilling and Milling Machine
Warranty:
Russia Buyes FREE TAX!!!
More Precise Stepping Motor
Simple operation and installation
1 year machine part and 6 months electrical parts,stepping motor,spindle Free Warranty
Upgrade new version can match windows-XP, 7. 8. 10 system
Free Gift :10pcsx3.175mm cnc tools
Introduction
This is a very good era,in the past we only can see the CNC machine equipment in factory, but now, the CNC equipment has been into our lives;
Whether you are a small or medium enterprises managers, project engineers, CNC enthusiast or artists, related students, there are something on this machine will attract you;
It can help you processing a lot of parts, whether you are modeling or home decoration or creative DIY.
It can help you intuitively to learn CNC knowledge. And testing learning outcomes in real time.
Warranty
More Precise Stepping Motor
Simple operation and installation
1 year machine part and 6 months electrical parts、stepping motor、spindle Free Warranty
Model and Technical Parameters
MODEL | 3020 metal | |||
Attribute | 3axis | 4axis | Only frame | |
Axis | 3axis | 4axis | 3axis | |
Interface | USB Port | USB Port | No | |
Spindle Motor: | 400W | 400W | No | |
Weigh | 22 | 26 | 16 | |
Max. working stroke | XYZ=180*270*95mm | |||
Acceptable material thickness | ≤95mm | |||
Rail type | X Y 1605 ball screw, Z 1204 ball screw, 12 mm optical axis | |||
Spindle motor | 400W DC spindle , 0-9000r/min | |||
Collet type | ER11,1/8"(3.175mm) Collet | |||
Stepper motor and drive | 57HS56 | |||
Repeat positioning Accuracy | 0.02mm | |||
Communication interface | USB Port | |||
System requirements | Win-XP / Win 7 Win 8 Win10 | |||
Software Co patability | Mach3/Emc2/Kcam, (Type3,Wentai, ArtCAM, coppercam) | |||
Command code | G code/.nc/.ncc/.tab/.txt | |||
Machine weight | 22kg | |||
Rotation Axis (4th Axis) Description: | Center height: H = 51mm Maximum turning diameter: ≤ 81mm Deceleration ratio: 4:1 Stepper motor: 57HS56 Weight: 4.0KG | |||
