Product Description
5kg/10kg Rotary Welding Positioner
This 10kg rotary welding positioner is a professional equipment for annular welding. It is mainly used to tilt, rotate the work pieces and keep them in horizontal or ship-shape position for further welding. You can put chuck on its working table or assemble clamping tools on this positioner, cooperate with manual welding works. This welding positioner can also be connected to automatic welding machine to ensure auto welding process. Good product with appropriate price!!!
High Capacity
0-90º Tiltable Table
Suitable Welding Gas
Anti-Slip Foot Switch
Tough Equipment & Tools, Pay Less
VEVOR is a leading brand that specializes in equipment and tools. Along with thousands of motivated
employees, VEVOR is dedicated to providing our customers with tough equipment & tools at incredibly
low prices. Today, VEVOR's products are sold in more than 200 countries and regions with 10 million
plus members worldwide. Why Choose VEVOR?
Premium Tough Quality
Incredibly Low Prices
Fast & Secure Delivery
30-Day Free Returns
24/7 Attentive Service
Kindly Remind:Since CE document wont delivery with goods, if you need CE document, please contact us feel free.
Key Features
High Capacity
Its horizontal/vertical loading capacity:10kg/5kg; Working table diameter/heigh: 18cm/7in.;23.2cm/9in. Made of stainless steel, features high quality and durablility.
0-90º Tiltable Table
The turning structure of worm and gear has the function of self-lock, and the worktable can be turned steplessly between 0-90°. It also can be fixed at any angle with tilt lock wrenches.
Suitable Welding Gas
Aside from supporting CO2 welding, it is also capable of MIG, MAG, TIG welding etc. May this lightweight and integral thing meet your various demand.
Anti-Slip Foot Switch
Using foot switch to control table rotation, the speed is regulated by the knob on the machine(2-20r/min stepless speed regulation).
Three-Jaw Welding Chuck
Three claws are reinforced to prevent the weldment pieces from moving and falling.It is upgraded to be more accurate and more practical.
Wide Application
For working table or specific tooling for clamping workpiece with manual welding,welding operation machine to achieve automatic welding, and for cutting, grinding, assembly, testing and other processes.
Specifications
Load Capacity: Max.10kg at 0°; Max.5kg at 90°
Rotating Speed: 2-20rpm
Tilt Angle: 0-90°
Mini chuck: KC-65
Table Diameter: 180mm
Voltage: 220V(EU/AU) 110V(US), 50/60 Hz
Height of Table: 232 mm / 9''
Motor Power: 15W
Rated welding current：80A
Drive motor: DC24V 15W
Workbench rollover: Manual
Application Chuck: KC-65
Product Weight: 10kg / 22LB
Package Content
1 X Rotary Welding Positioner
1 X KC-65 Chuck
1 X Foot Pedal
1 X Wire Cable
2 X Chuck Wrench
2 X Tilt Wrench
【WORKING CAPACITY: 5KG/10KG】- Horizontal/Vertical loading capacity:10 kg/5 kg; Working table diameter/height: 18 cm/7in.; 23.2 cm/9in. Made of stainless steel, features high quality and durability.
【0-90º TILTABLE TABLE】- The turning structure of worm and gear has the function of self-lock, and the worktable can be turned steplessly between 0-90°. It also can be fixed at any angle you want.
【THREE-JAW WELDING CHUCK】- Three jaws are reinforced to prevent the weldment pieces from moving and falling. It is upgraded to be more accurate and more practical.
【STEPLESS SPEED CONTROL】- Using foot switch to control table rotation, the speed is regulated by the knob on the machine(0.5-5r/min stepless speed regulation).
【WIDE APPLICATION】- Can be fixed on the working table or specific tooling for clamping workpiece with manual welding, can also be used with welding operation machine to achieve automatic welding, but also for cutting, grinding, assembly, testing and other processes.
