YIHUA 853D 1A USB 3IN1 Solder STATION Hot Air Gun SMD Soldering Iron
Features:
1.Based on the Company’s revolutionary, innovative design and meeting existing demands of the communication market, this all-in-one machine uses the latest chip technology and integrates a DC power supply, hot air gun, and soldering station!
2.Temperature controls utilize core technology, adopting microprocessor-PID programming for high-speed 100ms real-time tracking of air gun outlet temperatures and soldering iron tip temperatures, with real-time calibration! Outlet temperatures are extremely stable.
3. With PID high-speed 100ms rapid temperature calibration, conversions are energy-efficient, providing constant temperature power consumption at levels much lower than comparable machines, equating to greater energy savings!
4. The air gun handle wire employs a high-temperature silicone wire (undamaged when 300o soldering tip contacts silicone wire for 30 seconds), stainless steel tubing, and a cutting-edge ceramic framed heating core for extremely stable and reliable performance!
5. Celsius/Fahrenheit Display Temperature Function: To satisfy market demand in different regions, the Company has designed a temperature display mode.
6. The soldering iron features a sleep function that can be set 10 minutes.
7.This new type add to 5V output USB interface ,it more convenience repair mobile phone,also can use power supply for mobile.
8.All parts is LED digital display ,and the current is 4 digital precise display current value,the current value can precise display mA value.it is very directly perceived through the senses.
9.The soldering iron has an iron tip cleaner and internal rosin. The rosin aids in the soldering of circuit boards by removing oxide films on the iron tip, reproduces oxidation, reduces iron tip surface tension, and rapidly removes oxides.
10. Pioneering with handle safety protection, an industry-first, a docked handle in the handle holder is required each time prior to machine operation. If not (placed) in the handle holder, the operator will not be able to detect compliance with safety instructions and the machine will not work. The purpose of such a function is to prevent handle misplacement or accidental placement in unsafe or flammable (work) locations that could lead to undesirable consequences.
Technical data:
Rated voltage: AC 220V±10% 50HZ ( 110V±10% 50HZ)
Total Power: 700W+50W+15W=765W±10%(max)
Work environment : 0-50°C
Iron parts
Work Voltage :AC:26V±10% 50HZ
Temperature range:200°C-480°C
Temperature stability:±2°C
Tip of ground impedance:<2ohm
Tip of ground voltage:<2mV
Gun parts
Work Voltage: AC:220V±10% 50HZ\( 110V±10% 50HZ)
Temperature range:100°C-480°C
Temperature stability:±2°C
Dc power supply parts
Work Voltage:AC 20V±10% 50HZ\ ( 110V±10% 50HZ)
Output voltage:0-15V
Output current:1A
Load stability:<0.01±2mv
Recovery time:<100us
Ripple dB:<1mvrms (virtual value)
Temperature coefficient:<300PPm/°C
Protection starting current:>standard value 10%
